AC 300kgs lifting force Copper wire shutter door and luxurierous shutter door motor with an overheat prevention device
- Shanghai Ningbo Wuxi
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
AC 1000kgs rolling shutter door motor with an overheat prevention device
-
Wangwei AC heavy duty automatic sliding gate motor with manual and remote control
-
lifting force 1000kgs emergency brake
-
Wangwei AC 4000kgs heavy duty roller door motor
-
control board for sliding gate motor
-
600kgs Fireproof Door opener for double doors and accessories
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Wangwei | |
| Model Number | JDD-300-1P,JD-300-3P |
Product Description
Electric Motor Main Features
1.automatically open or close the doors by pressing relevant buttons
2. can be operated by electricity and manual.
3.can be remote controlled
4.with an overheat prevention device
5.with electronic anti-theft apparatus
6. Easy to install and operate
Technical Parameters(please note words in blue,model covers from 150kgs to 4000kgs)
| Ordinary door roll door models | Motor Power (W) | Rated voltage (V) | Rated current (A) | Output torque (N·m) | Reel diameter (φmm) | Output Speed (r/min) | Maximum lifting capacity (kg) | Maximum lift height (m) | No. use of chain |
| JDD-150-1P | 170 | 220V 50Hz | 3 | 85 | 114 | 8.3 | 150 | 6.5 | 8A |
| JDD-300B-1P | 230 | 3 | 210 | 140 | 5 | 300 | 10A | ||
| JDD-300-1P | 250 | 2.5 | 210 | 300 | |||||
| JDD-600-1P | 370 | 3.2 | 420 | 600 | |||||
| JD-300-3P | 200 | 380v 50Hz | 1.2 | 210 | 300 | ||||
| JD-600-3P | 400 | 1.4 | 420 | 600 |
Remarks:1.Disadvantage: Price may be not lowest.
Advantage: We are famous for rolling door motor in China. We ensure the quality(100%testing).Welcome your visiting, which is only 1.5hours driving to Shanghai.
2.Pls don't hesitate to contact us if you have any questions.
3.We can improve it as your designs without a large difference.
Mainly used in
Two choices for switch as following:
one set packed in two export cartons with foam(main motor,accessories)
540*265*210mm--main motor ctn size.G.w 11kgs
560*330*90mm--accessories ctn size.G.w 21kgs
FOB/CIF price or EXWORKS price
Whether to provide samples:not free,but revert after bulk order
Which port:Shanghai,Wuxi
Support what payment methods: before production after payment 50%,the other payment 50% before shipment
24 months after sale
Wuxi Weida Waite Electric Motor Co.,Ltd.
Contact:Apple Jo
Tel:86-510-66727327
MP:15052146627
Fax:88701396
Skype:applejoweida
Website: hrrp://wxwed.en.china.cn
Member ID:cnwxwed
Certificate:CCC,CE,ISO9001
