Single Cage Industrial Lift For transport personnel , equipment and material

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 0 Set / Sets per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	BORUIDA		Place of Origin	China
Model Number	CH-series

Product Description

Delivery Time:25-35 days
Certification:CE,ISO
Industrial Lift CH 1000 Single Car , 1000kg Capacity with Mast Hot-dip Galvanized

Quick Detail:

Name	Other Name	Brand Name	Control
Industrial hoists	Industrial hoists CH 1000	BORUIDA	DOL and FC
Loading Capacity	1000kg	Certificate	CE

DeCription:

Industrial hoists CH 1000 is installed and dismounted conveniently and can grow as high as the building grows height.The Industrial hoists has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment

Applications:

CH serialization of products Industrial hoists is a Rack and Pinion EL. Industrial hoists widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.

Specifications

Standard technical datas of single car :

Parameter	CH1000	CH1600	CH2000	CH2700	CH3200
Rated loading capacity (kg)	1000	1600	2000	2700	3200
Rated lifting speed (m/min)	0~40	0~40	0~60	0~60	0~60
Rated passenger number	12	18	24	30	38
Max. lifting height(m)	150	250	450	450	450
Engine power(kW)	2*9.5	2*11	2*13	3*18.5	3*22
Car inner dimension (LWH)(m)	31.32.5	31.42.5	31.52.5	3.21.52.5	3.61.62.5
Car weight (kg)	1400	1500	1800	1950	2050
Mast section weight (kg)	145	145	163	163	163
Mast section dimension (mm)	6506501508	6506501508	6506501508	6506501508	6506501508
Safety device type	SAJ30-1.2	SAJ40-1.2	SAJ40-1.4	SAJ40-1.4	SAJ50-2.0
Hanger rated lifting capacity (kg)	250	250	250	250	250
Rack module	8	8	8	8	8

CH series industrial hoists:

1). Car load capacity: 1000kg~3200kg;

2). Lifting speed:33m/min, 0~40m/min;0~60m/min;

3). Increased lifting height on request;

4). Mast section: Painted or hot dipped zinc

5). Car:double car

6). Recommended car inner dimensions (L*W*H): 3*1.3*2.5m, 3*1.4*2.5m, 3*1.5*2.5m, 3.2*1.5*2.5m, 3.6*1.5*2.5m,
