GL-E8080U 2 POTS WIFI GEPON ONU Fiber Optic Communication Equipment FTTH ONU HGU ONU FTTB Solution

GL-E8080U 2 POTS WIFI GEPON ONU Fiber Optic Communication Equipment FTTH ONU HGU ONU FTTB Solution

GL-E8080U（1GE+3FE+2POTS+WIFI）is an EPON user terminal,which meets the SOHO broadband access ,FTTH broadband speed ,FFTH/FTTD of cable-television operator.The equipment based on maturestable,cost-effective Gigabit EPON technology combines Gigabit Ethernet switching technology,WIFI and high-quality VoIP technology.It has high reliability,ease of administration and good QOS.The technology performance meets the IEEE802.3ah,China Telecom EPON equipment technical requirements (V2.1) specification requirements.

Special Features

1.Data service function

• Full speed without blocking exchange

• 8K MAC address table

• Support Full Range VLAN ID

• Support QinQ VLAN,1:1VLAN,VLAN Trunk etc.

• support port monitor, port mirror,port speed limit ,port SLA etc.

• QoS based on interface,IEEE 802.1p,IPV4(ToS),Diff-Serv,IPV6,802.1Q VLANID,destination MAC or source MAC.

• The Ethernet interfaces according to the specifications of the IEEE802.3.

• 128-bit AES encryption algorithm.

• According to 802.1x remote management and user authentication

2.Telephone service function

• Support SIP protocol，H.248 protocol，H.323 optional.

• Support ITU-T G.711,G.723.1,G.729 compression algorithm

• Echo cancellation meets ITU-T G.168-2002. echo cancellation for the longest is 128ms.

• Support OSPF,T38.

• Support RFC2833 and RFC2833 redundant,distinctive ringing ,MD5 certificate,call forwarding,call waiting,telephone hotline,alarm clock,abbreviated dialing and etc.

• Support two POTS interface three-way calling,three-way calling support local mixing.

• Support POTS GR909 line test function.

• Support dynamic PPPoE,dhcp and static IP.

• Support CTC2.1 standard

• 7×24h call lose≤0.01%
