High Pressure Seamless Carbon Bend Steel Tubing With Wall Thickness 1-15mm
Negotiable
MOQ: 1 Ton (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Place of Origin:
China
Model Number:
ASTM A192
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
SA192 SA192 SA210 SA213 Bending Steel Tube / Cold Drawn Steel PipeUS$ 800 - 1500MOQ: 1 Kilogram -
ISO9001-2008 Approved SA213 U Bend Tube , Bending Stainless Steel TubingUS$ 2000 - 5000MOQ: 1 Kiloampere
-
ASTM A179 U Bend Tubes Low Carbon Heat Exchanger Seamless Steel TubesUS$ 800 - 1500 /MOQ: 1 Piece
-
ASTM A688 Welded Austenitic 25mm Stainless Steel Tubes For Feedwarter HeaterNegotiableMOQ: 1
-
Seamless Carbon and Alloy Steel Mechanical Tube Machining 450mm DiameterNegotiableMOQ: 1 Piece
Place of Origin
China
Model Number
ASTM A192
Seamless Carbon Steel Boiler Tubes for High-Presure Service
Size range: O.D.:6-168mm W.T.:1-15mm L: according to customer requirement
Steel Grade and Chemical Compositions:
| C | 0.06-0.18 |
| Mn | 0.27-0.63 |
| P | ≤0.035 |
| S | ≤0.035 |
| Si | ≤0.25 |
Mechanical Properties
| Tensil Streghth: min ksi[Mpa] 47[325] | |
| Yield Point: min ksi[Mpa] 26[180] | |
| Elongation: ≥35% |
Hardness
| Brinell Hardness | Rockwell Hardness Numbe |
| WT≥0.200in(5.1mm) | WT＜0.200in(5.1mm) |
| 137HRB | 77HRB |
| Tolerance for OD and WT(SA-450/SA-450M) | |||||
| OD in(mm) | + | - | WT in(mm) | + | - |
| ＜1\'\'(25.4) | 0.10 | 0.10 | ≤1.1/2\'\'(38.1) | 20% | 0 |
| 1\'\'～1.1\'\'(25.4～38.1) | 0.15 | 0.15 | ＞1.1/2\'\'(38.2) | 22% | 0 |
| ＞1.1/2\'\'～＜2\'\'(38.1～50.8 | 0.20 | 0.20 | |||
| 2\'\'～＜2.1/2\'\'(50.8～63.5) | 0.25 | 0.25 | |||
| 2.1/2\'\'～＜3\'\'(63.5～76.2) | 0.30 | 0.30 | |||
| 3\'\'～＜4\'\'(76.2～101.6) | 0.38 | 0.38 | |||
| 4\'\'～＜7.1/2\'\'(101.6～190.5) | 0.38 | 0.64 | |||
| ＞7.1/2～9\'\'(190.5～228.6) | 0.38 | 1.14 |
Applications: for Boilers,Superheaters,Heat-Exchangers, high-pressure
