EN10305-1 Telescopic Cylinders Gas Cylinder Seamless Cold Drawn Steel Tube

EN10305-1 Telescopic Cylinders Gas Cylinder Tube with Cold Processing Production

Standard: EN10305-1 Seamless Cold Drawn/Rolling Steel Tubes


Steel Tubes for precision applications.


Applications: for Gas Cylinder Applications, Oil Cylinders/Telescopic Cylinders


Size Range: O.D.:6-380mm     W.T.:1-35mm      L:max12000mm

Steel Grade: E235, E355,E215 etc

Steel Grade and Chemical Compositions:

Note: Special steel grade is also available, according to customer request.

aRm: tensile strength;  ReH: upper yield strength; A: elongation after fracture

b 1Mpa=1N/mm2
c Depending on the degree of cold work in the finishing pass the yield strength may nearly be as high as the tensile strength.
For calculation purposes the following relations are recommended:
for delivery condition +C: ReH ≥0.8 Rm
for delivery condition +LC: ReH ≥0.7 Rm
d For calclulation purposes the following relation is recommended:ReH≥0.5Rm
e For tubes with outside diameter ≤30mm and wall thickness ≤3mm the ReH minimim values are 10Mpa lower than the values given in this Table
f For tubes with outside diameter＞160mm: ReH≥420Mpa
