ASTM A519 1010 1020 1026 4130 4140 Seamless Carbon and Alloy Steel Mechanical Tubing

ASTM A519 1010 1020 1026 4130 4140 Seamless Carbon and Alloy Steel Mechanical Tubing thumbnail-1
ASTM A519 1010 1020 1026 4130 4140 Seamless Carbon and Alloy Steel Mechanical Tubing photo-1
US$ 600 - 1200 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
TORICH
Place of Origin:
China
Model Number:
ASTM A519
Contact Supplier Request Quote Chat Now
Torich International Co.,ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name TORICH
Place of Origin China
Model Number ASTM A519
Delivery Time:35-60 days
Certification:ISO 9001 ISO 14001 EN 10204.3.1 TS 16949 CCS SON PED

ASTM A519 1010 1020 1026 4130 4140 Seamless Carbon and Alloy Steel Mechanical Tubing

ASTM A519 Seamless Carbon and Alloy Steel Mechanical Tubing


Applications: for mechinery, mechanical engineer


Size range: O.D.:6-350mm     W.T.:1-50mm      L:max12000mm

Special Smoothness Inside Surface,SSIS
this tubing is intended for use where the inside surface is of prime importance.
Usually we leave maching allowance for both OD and ID tolerance for further maching purpose.

Mothod of tube forming:
1. Hot-Finished Mechanical Tubing
2. Cold-Worked Mechanical Tubing
3. Rough -Turned Mechanical Tubing
4. Ground Mechanical Tubing

Thermal Treatment:
1) A-Annealed
2) N-Normalized
3) QT-Quenched and Tempered
4) SR-Stress relieved or Finish Anneal

                                       Steel Grade and Chemical Compositions:
Steel  C Mn P S Si Cr Mo
Grade max   max max max min
1008 0.10  0.30-0.50 0.040  0.050
1010 0.08-0.13 0.30-0.60 0.040  0.050
1018 0.15-0.20 0.60-0.90 0.040  0.050
1020 0.18-0.23 0.30-0.60 0.040  0.050
1026 0.22-0.28 0.60-0.90 0.040  0.050
1035 0.32-0.38 0.60-0.90 0.040  0.050
1045 0.43-0.50 0.60-0.90 0.040  0.050
4130 0.28-0.33 0.40-0.60 0.040  0.040  0.15-0.35 0.80-1.10 0.15-0.25
4140 0.38-0.43 0.75-1.00 0.040  0.040  0.15-0.35 0.80-1.10 0.15-0.25
Grade Condition Ultimat  Yield  Elongation Rockwell
    Strength  Strength   Hardness
    ksi    Mpa ksi    Mpa % B Scale
1020 HR 50     345 32      221 25 55
  CW 70     483 60      414 5 75
  SR 65     448 50      345 10 72
  A 48      331 28      193 30 50
  N 55      379 34      234 22 60
1035 HR 65      448 40      276 20 72
  CW 85      586 75      517 5 88
  SR 75      517 65      448 8 80
  A 60      414 33      228 25 67
  N 65     448 40      276 20 72
1045 HR 75      517 45      310 15 80
  CW 90      621 80      552 5 90
  SR 80      552 70      483 8 85
  A 65      448 35      241 20 72
  N 75     517 48      331
