Help Center2015 High Quality Aluminum Truss, Stage Truss, Roof Truss for Sale
Related Products
-
Hot Sale Aluminum Lighting Tower Truss Stage TrussUS$ 70 - 70MOQ: 1 Kilogram -
Aluminium Truss Exhibition Booth ,truss Display, Display TrussUS$ 70 - 70MOQ: 1 Kilogram
-
Outdoor Event Lighting Aluminium Truss, Aluminum Truss for Trade ShowUS$ 70 - 70MOQ: 1 Kilogram
-
Specialized Aluminum Outdoor Stage/outdoor Concert Stage/outdoor Stage Truss DesignUS$ 1000 - 1000MOQ: 1 Kilogram
-
Professional Stage Design Aluminum Stage for ShowUS$ 1000 - 1000MOQ: 1 Kilogram
Tourgo Electronics Co., Ltd. Supply all kinds of Truss, such as Aluminum Bar Table, Aluminum Bar Chair, Aluminum Truss, Bolt Truss, Spigot Truss, Truss system, Screw Truss, Speaker Trusses, Lighting Trusses...Etc
TG aluminum trusses are commonly used in a variety of different fields. Our truss are easy to be set up & disassembled. From small lighting designs, exhibition and display booths to a large scale stage structures, you always could find a convenient solution and guidance from us.
We have professional engineer team to design the most satisfactory truss system according to your requirements. We have full experience to offer you the most cost performance solution. With our outstanding quality and excellent service, come on let's dress up your events in a worriless way!
What's spigot truss and bolt truss?
Spigot truss system is defined by the connection of the trussing segments by spigots. There is always a female set of spigot connectors on one side of the truss and a male set on the other so the segments can be put together easily. The connection is secured by special spigot truss pin
Bolt truss represents a traditional type of connection. The trussing segments are connected by bloting aluminum plates together
Spigot truss sizes:
230x230mm / 290x290mm / 390x390mm / 520x520mm and etc
Bolt truss sizes:
100x100mm / 150x150mm / 200x200mm / 250x250mm / 300x300mm / 350x350mm / 400x400mm, 450x450mm / 400x600mm / 500x500mm / 500x600mm / 520x760mm / 600x760mm / 760x910mm and etc
Some examples of weight loading capacity:
250*250mm 50*3mm 25*2mm 350KG 10M
300*300mm 50*3mm 30*2mm 375KG 14M
350*350mm 50*3mm 50*2mm 450KG 15M
400*400mm 50*3mm 50*2mm 475KG 16M
450*450mm 50*3mm 50*2mm 500KG 17M
500*500mm 50*3mm 50*2mm 550KG 19M
500*600mm 50*3mm 50*2mm 600KG 20M
760*520mm 50*4mm 50*2mm 1000KG 22M
760*600mm 50*4mm 50*2mm 1500KG 26M
