Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Waterproof Level: IP65(Front Side), IP54 (Back Side)
2. Lightweight :< 8.5KG/panel. Ultra thin: 95mm thickness
3. High brightness: >6000cd/㎡
4. CE,CCC,RoHS,UL,ISO9001
5. Made by high quality aluminum material
6. Cabinet connection angle can be adjusted by -15 degree to +15 degree
P7 Waterproof Outdoor Transparent LED Screen Curtain For Show
Description:
1. Waterproof & High brightness
Brightness reaches 6000nits, IP65. It is perfect to be used for both indoor and outdoor.
2. Light Weigh & Ultra Thin
Made by high quality aluminum material, one cabinet only weights 8.5 KG. It makes installation job and
delivery more comfortable and convenient. 95 mm thickness saves not only space for delivery but also
installation.
3. ngle Adjustment
Cabinet connection angle can be adjusted by -15 degree to +15 degree. This allows you shape arc
shapes.
4. Fast Lock System & No Fan Design
Easy to install and dismantle: an average worker can finish 70 panels per hour. Natural cool system design
and good heat dissipation.
Applications:
Events, Rental, Show, Exhibition, Stage, Entertainment, Concerts
Specifications:
1. WS7 Technical Parameter
|
Model No. |
WS7 |
|
Pixel Pitch |
7.81mm |
|
Module Size |
500mm*62.5mm |
|
Module Resolution (W*H) |
64 dots*8 dots |
|
Pixel Density |
16384 dots/ ㎡ |
|
LED Type |
SMD 3535 |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/4 Duty Constant Current |
|
Cabinet Size |
500×500×95mm |
|
Cabinet Resolution |
64dots×64dots |
|
Brightness |
≥7000cd/㎡ |
|
Contrast |
≥4000:1 |
|
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
|
Best Viewing Distance |
7m-300m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
1500 W/m2 |
|
Average Power Consumption |
700 W/m2 |
|
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
60-85 HZ |
|
Refresh Frequency |
240 - 1000HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
-40~+65℃ |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
|
MTBF |
≥50,000 hours |
|
Computer Operation System |
Win 98/ Win XP/ Win 2000 |
|
Video Signa |
