Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Lightweight :< 12.5KG/panel. Ultra thin: 100mm thickness
2. High brightness: more than 6000cd/㎡
3. Waterproof Level: IP65(Front Side), IP54 (Back Side)
4. CE,CCC,RoHS,UL,ISO9001
5. Made by good aluminum material
6. Cabinet connection angle can be adjusted by -15 degree to +15 degree
Outdoor IP65 P12 Transparent LED Screen , Ultra Thin LED Display
Description:
1. Lightweight & Super Thin
Made by good aluminum material, one panel only weights 12.5 KG. It enables the installation job and
delivery job very comfortable and convenient. Thin thickness not only saves space for delivery but also for
installation environment.
2. High brightness & Waterproof
Brightness reaches 6000nits, Waterproof IP65. The product can be used for indoor and outdoor.
3. Angle Adjustment
Cabinet connection angle can be adjusted by -15 degree to +15 degree. You can shape the LED panel as
arc shape.
4. Fast Lock System & No Fan Design
Fast lock system design enables the installation faster and easier. An average worker can complete 50-70
panels within one hour. Nature cool design generates better dissipation and less power consuming.
5. Comprehensive Usage
With Above features, the product can be used for multi purposes: rental and fix installation, events, trade
show etc.
Applications:
Rental, Advertising, Stage, Events, Show, Exhibition, Entertainment, Concerts
Specifications:
1. WS12 Technical Parameter
|
Model No. |
WS12 |
|
Pixel Pitch |
12.5mm |
|
Module Size |
500mm*100mm |
|
Module Resolution (W*H) |
40 dots*8 dots |
|
Pixel Density |
6400 dots/ ㎡ |
|
LED Type |
SMD 3535 |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/6 Duty Constant Current |
|
Cabinet Size |
500×1000×100mm |
|
Cabinet Resolution |
40dots×80dots |
|
Brightness |
≥6000cd/㎡ |
|
Contrast |
≥2000:1 |
|
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
|
Best Viewing Distance |
7m-300m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
1200W/m2 |
|
Average Power Consumption |
600 W/m2 |
|
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
60-85 HZ |
|
Refresh Frequency |
240 - 1000HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
-40~+65℃ |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
