Pulls Strand Film Granulator for plastic recycling High Capacity 50 - 1000kg/h

Delivery Time:50 working days
Certification:CE

Pulls strand Film Granulator for plastic recycling

Quick Detail for Pulls strand Film Granulator for plastic recycling:

·  CE certificate

·  Low noise and low power consumption

·  Longer using life

·  Stable output

·  Perfect after sales service

·  Provide engineer debugging

Description for Pulls strand Film Granulator for plastic recycling:

A. Features of pulls strand film granulator:

1. High efficiency
Compared with the primary design,the output of PURUI second generation film granulator machine has been increased 20%.

2. Low power consumption
The power consumption reduced 15% compared with the primary design,.

3. Highly automatically,

Only 2 people for one production line.

B. Applications of film granulator:

Applicable plastic materials: PE,  HDPE, LDPE,PP, BOPP, PET, PA, EPE, etc

Material shapes: film, bag, , non woven fabric, crushed material(PE, PP)

Material types: (rolls, loose, bundled),

Material comes from offcut,below standard film and washed film.

Note: depending on different material properties, various downstream equipments are needed.

C. Machine components

No.	Machine name	Qty
1	Belt conveyor	1
2	Compactor	1
3	ML main machine	1
4	Hydraulic screen changer	1
5	Water tank	1
6	Gale dryer	1
7	Vibration(operational)	1
8	Wind transmission system & silo storage	1
9	Electric control cabinet	1

Specifications:

Main Technical Parameter:

Normal:

Model	Screw diameter(mm)	L/D	Output(kg/h)
ML85	85	25~33	120~180
ML100	100	25~42	200~350
ML130	130	25~36	400~550
ML160	160	25~33	600~800
ML180	180	25~33	800~1200

High output,low consumption:

Model	ML85B	ML100B	ML130B	ML160B	ML180B
Output(kg/h)	200-350	400-550	600-800	800-1200	1000-1500

Competitive Advantage:

1. High automation level, try best to reduce your cost on labor and ensure high processing capacity.

2. All parts contacting with plastic material and water are made of high-quality 304 stainless steel; Ensure no second pollution to flakes.

3. Very low  designated energy consumption and maintenance costs,ensure the lowest operating cost.

Full-automatic: free the human labor

The granulator line need at most 2 persons.

Waste plastic material(e.g. Film, fiber) is fed into cut compactor automatically by belt conveyor (roll-intake device is available to equip as option). In-feed rate is controlled via motor amperage of the cut compactor, therefore, there is no need for manual dosing by operator.
