Automatic Steel Coil Slitting Line 15MT With High Speed

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	BZ		Place of Origin	China
Model Number	ZJX-3X1600

Product Description

Delivery Time:in 90days

Automatic Steel Coil Slitting Line 15MT With High Speed

Specifictions

Item	Steel slitting line
Coil Material Specifications Kind provide the detailed information with the inquiry	Thickness	0.3-3mm
Coil width	500-1550mm
Material	PPGI,CRS
Coil weight	15T
Coil I.D	480mm-510mm
Coil O.D	1600MM
Decoiler and Recoiler	Type	Hydraulic&Motorized
Coil Width	Max. 1600mm
I.D	480-510mm
O.D	Max. 1600mm
Capacity	15T(Max)
Scrap winder I.D	420mm
Blade Specifications	dimension	200mmx340mmx15mm
material	6CrW2Si
hardness	HRC58-60
Slitting line specifications	Line speed	0-120m/min
Power	380V/50HZ/3 PH
Dimension	30M(L)x8m(W)
Slitting width tolerance	≤±0.05mm/2m
Operation workers needed	1 technician and 2 common workers

Main Components of the slitting line

Hydraulic entry coil car	1 Unit
Hydraulic decoiler	1 Unit
Press and pinch device	1 Unit
Hydraulic head cutter	1 Unit
Side guide device	1 Unit
Slitter	1 Unit
Scrap winder	1 Unit
Tension stand	1 Unit
Recoiler	1 Unit
Hydraulic exit coil car	1 Units

Application

It is applied to do the high speed slitting and rewinding for the CRS, Galvanized steel and stainless steel, HRS and so on.

Use in great production factory with high output

Features:

1. Adopt good PLC control system, high degree of automation.

2. Adopt reliable hydraulic system and hydraulic elements.

3. Electronics adopts famous wrld brands,quite reliable.

4. Adopt good mechanical design with high solidity and strength.

Company Introduction

Wuxi Bangzhou Machinery Manufacturing Co., Ltd. is located in Jiangyin, Wuxi City. We are one of the most professional machinery manufacturers in China, integrating design, production, sale and after-sales services.

Our main products are Steel coil slitting lines, cut to length lines, Flat bar chamfering, deburring and straightening machines, . Our products are supplied to roll forming machine and pipe welding factories and can be also applied to other industries which connect to the metal material.
With our best service and machines\' high quality,we have gained a great reputation in the field

We welcome all friends to visit us. We are sincerely looking forward to receive your guidance and business cooperation!
