raymond pendulum mill

Introduction:

Raymond pendulum mill, also known as raymond roller mill , raymond grinding mill and raymond grinder, is suitable for grinding non-flammable and non-explosive materials whose Moh’s hardness is below 9.3 and humidity less than 6% such as barite, calcite, potassium feldspar, talc, marble, limestone, dolomite, fluorite and lime, activated clay, activated carbon, bentonite, kaolin, cement, phosphate rock, gypsum, glass and thermal insulation material in mine, metallurgy, chemistry and building industry.

The structure of Raymond pendulum mill has been perfected after years of practice and improvement. It is widely used for grinding materials in metallurgy industry, building materials industry, chemical industry, mining industry and other areas. It can meet the requirements of different customers with the interaction of the analyzing machine and fan.

Applied Materials of Raymond pendulum Mill:

It is suitable for processing various non inflammable minerals with 7 grade Mohs hardness and less than 6% humidity, such as gypsum, talc, calcite, limestone, marble, feldspar, dolomite, barite, granite, kaolin clay, stone, bauxite, oxide iron red, iron ore, etc. The fineness of its finished product is 613-44 microns (0.613 mm -0.044 mm).

Working Principle:

When Raymond pendulum mill works, the materials that need to be crushed are fed into the machine through the feeding hopper. The grinding roll that hangs on the main engine will rotate around the vertical axis and rotates around itself. Due to the centrifugal force produced in the rotating process, the grinding roll will swings outward and tightly press onto the grinding ring to make the relieving tool scoop up the materials and send them to the space between the grinding roll and the grinding ring, and the materials will be crushed due to the rolling and grinding of the grinding roll.

Performance Features of Raymond Pendulum Mill:

1. Strong systematicness and high pass screening rate.

This pulverizer machine adopts stereochemical structure, which covers small area, and has an independent production system from roughly grinding raw materials to the final packaging. The finished production fineness is on average and the pass screening rate is 99%.

2. Stable transmission and high wear-resistance

The transmission device adopts sealing gear box and belt wheel, which make sure the machine stable transmission and reliable operation. The core parts are made of high-performance and wear-resistant materials to improve the wear-resistant performance and save cost.

3. Easy to control and convenient to maintain

If you would like to know more information about Raymond pendulum mill, such as raymond pendulum mill price and the minimum order quantity, please contact us. In addition, we also provide Raymond mill parts at a reasonable price. Welcome to your inquiry!

/
