Help CenterCarbon Steel Door Frame Making Machine , Automatic 15kw Cold Roll Forming Equipment
Related Products
-
High Efficiency Automatic Door Frame Roll Forming Machine With Gear Box DrivenUS$ 45000$ - 100000$MOQ: 1 Piece -
High Precision Metal Door Frame Roll Forming Machine Line With 5 RollersUS$ 35000$ - 60000$MOQ: 1 Piece
-
Professional Full - Automatic Window / Door Frame Roll Forming Machine 0-15m/minUS$ 35000$ - 60000$MOQ: 1 Set
-
Automatic G.i Coil Door Frame Roll Forming Machine With PLC Control SysetmUS$ 35000$ - 60000$MOQ: 1 Piece
-
Color Steel Continuous Polyurethane Sandwich Panel Making Line With High Press FoamingUS$ 200000$ - 400000$MOQ: 1 Set
Certification:CE
Standard Speed Door Frame Roll Forming Machine For 0.8 - 1.6Thickness Corbon Steel, With PLC Control Sysetm
Description
Our main products include PU sandwich panel production line, PURLIN ROLL FORMING MACHINE, STEEL SILO ROLL FORMING MACHINE, guardrail roll forming machines , metal roofing /decking/cladding roll forming machines , roof tile roll forming machines ,door & window frame roll forming machines , guide rail roll forming machines, upright post roll formers, gutter machines and downspout machines , T-bar forming machines , stud and track forming machines, cable tray roll forming machines, roller shutter manufacturing lines and so on.
Composition of machine
|
Roll forming main machine |
1 unit |
|
5 TONS Un-coiler |
1 unit |
|
PLC Control panel |
2 unit |
|
Punching system |
1 unit |
|
Hydraulic station |
1 unit |
|
Hydraulic cutting device |
1 unit |
|
Safety cover device |
1 unit |
|
Manual out table |
2 unit |
Specifications
|
Coil Material |
Thickness |
1.2-2.5mm |
|
Coil width |
Depend on customer’s requires |
|
|
Yield Strength |
250-350Mpa |
|
|
Material |
G.i Coil or Carbon steel |
|
|
Decoiler / Uncoiler |
Coil Width |
Max. 1000mm |
|
I.D |
510-610mm |
|
|
O.D |
Max. 1200mm |
|
|
Capability |
Max. 5Tons |
|
|
Decoiler type |
Manual / Hydraulic/Automatic |
|
|
Feeding & guiding |
Pinch feeding |
1 Units ( 2 Rollers ) |
|
Levelling |
5 Rollers |
|
|
Cutting device |
Cutting motion |
Hydraulic Cutting( cutting sheet after forming ) |
|
Cutting blades |
Cr12Mov with heat treatment HRC58-62 |
|
|
Length Measuring |
Automatic length measuring by encoder & PLC. |
|
|
Cutting Tolerance |
1.5mm(per 3m) |
|
|
Roll Forming Machine |
Forming Stations |
ABOUT 24 steps |
|
Roller material |
GCR15, heat treatment |
|
|
Diameter of shaft |
80mm |
|
|
Shaft material |
High grade 45# steel |
|
|
Drive type |
Gear box driven |
|
|
Forming speed |
0-15m/min |
|
|
Main power |
15kw |
|
|
Electrical control |
PLC |
PANASONIC Brand or Custom-made |
|
Inverter |
YASKAWA Brand or Custom-made |
|
|
Touch screen |
MCGS Brand or Custom-made |
|
|
Operation type |
Touch screen & Button |
|
|
Hydraulic Station |
Hydraulic station |
Famous Chinese brand |
|
Hydraulic power |
30KW |
|
|
Runout Table |
Table type |
Simple non-power type |
|
Function |
To support the finished panels |
|
|
TOTAL WEIGHT |
