High efficiency Automatic Door Frame Roll Forming Machine with Gear box driven

Place of Origin

China (mainland)

Brand Name

ZOOY

Model Number:

ZO-DF240

Raw Material

 G.i Coil or Carbon steel

Certificate

CE

Warranty

1 YEAR

Roll forming main machine

1 unit

5 TONS Un-coiler

1 unit

PLC Control panel

2 unit

Punching system

1 unit

Hydraulic station

1 unit

Hydraulic cutting device

1 unit

Safety cover device

1 unit

Manual out table

2 unit

Coil Material

Thickness

1.2-2.5mm

Coil width

Depend on customer’s requires

Yield Strength

250-350Mpa

Material

       G.i Coil or Carbon steel

Decoiler / Uncoiler

Coil Width

Max. 1000mm

I.D

510-610mm

O.D

Max. 1200mm

Capability

Max. 5Tons

Decoiler type

Manual / Hydraulic/Automatic

Feeding & guiding

Pinch feeding

1 Units ( 2 Rollers )

Levelling

5 Rollers

Cutting device

Cutting motion

Hydraulic Cutting( cutting sheet after forming )

Cutting blades

Cr12Mov with heat treatment HRC58-62

Length Measuring

Automatic length measuring by encoder & PLC.

Cutting Tolerance

1.5mm(per 3m)

Roll Forming Machine

Forming Stations

ABOUT 24 steps

Roller material

GCR15, heat treatment

Diameter of shaft

80mm

Shaft material

High grade 45# steel

Drive type

Gear box driven

Forming speed

0-15m/min

Main power

15kw

Electrical control

PLC

PANASONIC Brand or Custom-made

Inverter

YASKAWA Brand or Custom-made

Touch screen

MCGS Brand or Custom-made

Operation type

Touch screen & Button

Hydraulic Station

Hydraulic station

Famous Chinese brand

Hydraulic power

30KW

Runout Table

Table type

Simple non-power type

Function

To support the finished panels
