YANMAR Engine Diesel Fork Lift Truck With Cascade Side Shift , 3 Ton Forklift CPCD20J

YANMAR Engine Diesel Fork Lift Truck With Cascade Side Shift , 3 Ton Forklift CPCD20J photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
JAC
Place of Origin:
China
Model Number:
CPCD20
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Brand Name JAC
Place of Origin China
Model Number CPCD20
Delivery Time:20-25 WORKING DAYS
Certification:CE / SGS / ISO9001 / ISO14001 / SGS

ISUZU ENGINE 3.0 Ton JAC CPCD30J  Diesel Forklift Material Handling Truck

Quick Detail:

1. 3000kg rated capacity, 3000mm lifting height, 500mm load center

2. Sea Port, Airport, Warehouse, Construction, factory

3. Material Handling, loading & unloading cargo, moving cargo in pallets

4. ISUZU engine, YANMAR engine

5. Diesel forklift truck, Diesel forklift, Diesel Fork Lifter

6. 3.0Ton Diesel Forklift Material Handling Truck Chinese ENGINE

7, Load Capacity: 3000KG

8, Engine:ISUZU / YANMAR / JAC Engine / VM Engine / Chinese Engine

9, Transmission: Hydraulic/Auto (with TCM Technology)

10, Standard Mast: Standard 2-Stage Tower Mast (3.0m)

11, Container Mast(Optional): Duplex / Triplex full free Mast (3.0m-6.0m)

Description:

HS Code: 8427109000

Trademark: JAC

Export Market: Global

Certificate: CE / SGS / ISO9001 / ISO14001 / SGS

Production Capacity: 20000 unit/year.

Forklift Type: Diesel Forklift Truck

Model Number: CPCD20J

Load Capacity: 3000KG

Engine:ISUZU / YANMAR / JAC Engine / VM Engine / Chinese Engine

Transmission: Hydraulic/Auto (with TCM Technology)

Standard Mast: Standard 2-Stage Tower Mast (3.0m)

Container Mast(Optional): Duplex / Triplex full free Mast (3.0m-6.0m)

Tyre: Pneumatic Tyre (Standard) Solid Tyre (Optional)

Side shift (optional): Integral side shift / Cascade side shift

Applications:

Material Handling, airport, sea port, super market,moving cargo in pallets in warehouse,3.0Ton Diesel Counterbalance Forklift Material Handling Truck ISUZU ENGINE, loading & unloading cargo, factory building, storage yard,

Specifications:

    CPCD25
POWER UNIT   DIESEL
LOAD CAPACITY kg 3000
LOAD CENTER mm 500
SERVICE WEIGHT kg 4280
STANDARD LIFT HEIGHT   3000
LENGTH TO FORK FACE mm 2740
OVERALL WIDTH (STANDRD/DOUBLE FRONT TYRE) mm 1230/1710
HEIGHT OF OVERHEAD GUARD mm 2105
AISLE WIDTH WITH PALLET mm 3930
1000*1200 ACROSS FORKS
TURNING RADIUS mm 2500
TRAVEL SPEED, WITH/WITHOUT LOAD km/h 19.5/17
ENGINE FOR OPTION   JAC ISUZU VM
    4DC1 C240PKJ-30 753IE4
ENGINE BRAND   JAC ISUZU VM
FUEL TYPE   DIESEL DIESEL DIESEL
ENGINE TYPE   4DC1 C240PKJ-30 753IE4
RATED POWER   45/2500 35.4/2500 50/2500
MAX.TORQUE   185/1600 137.7/1800 250/1800
NUMBER OF CYLINDERS/DISPLACEMENT(L)   4/3.059 4/2.369 3/2.2
BORE * STROKE (mm)   94.5*107 86*102 94*107
EMISSION REGULATION EC STAGE 3A EC STAGE 3 EC STAGE 3B EC STAGE 3A

Competitive Advantage:

1. Stream-line design: Exclusive streamline design, fashionable and spirituality.

2. The new counterweight design, more beautiful appearance.

3. Flush door frame.


4. Large driving
