8W 900Lm Outdoor Lighting Bridgelux LED Module With EN62471

Delivery Time:5-10 days
Certification:CE, RoHS, EN62471

900lm 8W high power led module with Bridgelux 45mil chip for outdoor lighting

Quick Detail:

8W power consumption Integrated package, high light efficiency Bridgelux 45mil led chip 24-27V,320mA, up to 110lm/W,Ra>70 Size: 20mm*20mm Warm white/Neutral white/Cool white optional Excellent thermal conductivity, well heat dissipation to reduce the light decay and extend the lifetime of the light source. Suitable for wide range applications, he variety of working environment. High light efficiency but low power consumption. With compact structure and convenient for welding operation. 2 years warranty

8W 900Lm Outdoor Lighting Bridgelux LED Module With EN62471

Description:

With compact structure and convenient for welding operation. Integrated package, 8-15W different power customized Super high lumens light source Several led chips available, easy selection with your goal. Thermal conductivity design, well heat dissipation to reduce the light decay and extend the lifetime of the light source.

Applications:

Flood light High bay light Track light Down light

Specification:

Dimension

Electrical/Optical Characteristics (At TA=25°C)

Parameter	Symbol	Conditions	Min.	Avg.	Max.	Units
Luminous Flux	Φ	IF=320mA	800	--	900	lm
Color Rendering Index	CRI	IF=320mA	− −	70	− −	Ra
Color Temperature/ Color coordinates	CCT	IF=320mA	2800	--	6500	K
Forward Voltage	VF	IF=320mA	24	--	27	V
Luminous efficiency	Φ	IF=320mA	90	--	100	Lm/W
Thermal Resistance Junction To Board	RΘJ-B	IF=320mA	− −	2	− −	°C/W
Reverse Current	IR	VR=17V	− −	− −	2	μA
Viewing Angle [1]	2Θ1/2	IF=320mA	− −	130	− −	Deg

Absolute Maximum Rating(At TA=25°C)

Parameter	Symbol	Ratings	Units
Power Dissipation	PD	8	W
Continuous Forward Current	IF
