Specifications
Enameled Copper Clad Aluminum Wire Used for Electrical Machine:1.High resistant
2.Magnet wire
3.Round shape
Enameled Copper Clad Aluminum Wire Used for Electrical Machine
1.Description
Insulation: Polyester,Polyurethane,Polyester-imide
Class:130 B/155 F/180 H/200 C/220 C+
Diameter:0.10mm--5.00mm
Copper Percentage: 10% copper , 30% copper and 40% copper
2.Application
Used as the winding wire demanding light weight, high conductivity, heat dispersion performance, especially for the winding wire transferring high frequency signal such as the winding wire of high frequency transformer, common transformer, electric induction coil, miniature electric machine and so on
3. Performance Features
(a) Good conductivity of copper,light weight of aluminum
(b) High signal transmission property
(c) Direct soldering, good colorability , high adhesiveness
(d)Thermal stability . high thermal endurance . high temperature softening breakdown
(e)HF-resistance , solvent resistance and chemical property resistance to winding damage
4.Packing
Plastic bobbin: |
PT-4 |
PT-10 |
PT-15 |
PT-25 |
Take up wire size(mm) |
0.12~0.15 |
0.16~0.21 |
0.23~0.59 |
0.6~0.85 |
CMB/carton |
0.02 |
0.0175 |
0.021 |
0.0167 |
Spool/carton |
4 |
2 |
2 |
1 |
Net weight(kg/spool) |
2.5 |
4.5 |
7 |
12 |
