High Speed Galvanised Roofing Sheet Roll Forming Machine With Hydraulic Cutting

Delivery Time:55-65 working days
Certification:CE

High Speed Galvanised Roofing Sheet Roll Forming Machine With Hydraulic Cutting

  Characteristic of Roofing Sheet Roll Forming Machine

1. This Roofing Sheet Profile Roll Forming Machine can rollform galvanised iron roofing panel sheet. After roll formed by this roofing sheet roll forming machine, the surface of iron metal roof sheet panel is very smooth and beautiful without any scratch on the surface of profile sheets.

2. The Roof Sheeting Roll Forming Machine is with fully automatic control system with PLC.

3.  Length, quantity of sheets is adjustable.

4. Easy operation: Key in the length and quantity on the control panel.

5.  Rollforming process: Decoiler, Rollforming, Cut to length.

6. 1 Year warranty, lifelong time service.

7. We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.

  Reference Specifications of Roofing Sheet Roll Forming Machine

Material thickness: 0.3-0.8mm Material width: depend on customer’s requirement Decoiler Type: manual or automatical type ( depend on customer’s requirement ) Weight Capacity Of Decoiler: 5 Ton Main Motor Power: 5.5 Kw Hydraulic Motor Power: 3 Kw Forming Station of Roofing Sheet Roll Forming Machine: 16 ( depend on profile drawing ) Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface. Main Axis Material: High grade 45#, quenched and heat treatment. Axis Diameter: ¢ 76mm Working Speed: 0-15 m/min Drive Type: Chain Transmission Heat Treatment of Cutting Blade: HRC 50-60 Type of Cutting: Hydraulic cutting Material Of Cutting Blade: C r 12 Heat Treatment of Cutting Blade: HRC 50-60 Machine Frame stand: Welded structural steel Thickmess of Fame Steel: 18mm Electrical Control: PLC Frequency Control System with touch screen PLC: PANASONIC Brand Encoder: OMRON Brand Transducer: PANASONIC Brand Machine Weight: about 5 Ton

  Compostion of Roofing Sheet Roll Forming Machine

Decoiler / Uncoiler	1 Unit
Feeding Guide	1 Unit
Roofing Sheet Roll Forming Machine	1 Unit
Hydraulic Cutting System	1 Unit
Hydraulic Station	1 Unit
PLC Computer Control Box	1 Unit
Support Tables	2 Units

  Reference Roofing Drawings

  Our Advantage

High Quality Reasonable Price Good after Service 1 Year Warranty More Than 10 Years Experience
