Home > Products > Square End Mill > Custom Carbide TiAlN coated Square End Mill CNC High Precision Cutting Tool HRC60
Custom Carbide TiAlN coated Square End Mill CNC High Precision Cutting Tool HRC60
- 0 Square Meter / Square Meters per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
High speed HRC60 Square End Mill Standard with 45 helix Angle for Stainless Steel
-
Long Flute HRC60 Carbide End Mill High Precision CNC Cutter for Side Milling 0.3-0.4um
-
HRC60 Long Neck Carbide Two flute Square End Mill high Speed Slotting End Mills
-
4 Flute HRC 60 Square End Mill TiAlN Coated Long Neck High Speed Milling , Standard Type
-
4 Flute End Mill HRC60 TiAlN Coated End Mills with Super Fine Grain Size Extra Long
-
HRC50 Carbide Ball Nose End Mill Mirco Grain Cutting Tool Endmill Roughing to Finishing
Product Details
| Brand Name | INMIND | Place of Origin | China | |
| Model Number | Standard Length type 1mm to 20mm |
Product Description
Certification:SGS Factory Certificater
Custom Carbide TiAlN coated Square End Mill CNC High Precision Cutting Tool HRC60
Quick Detail:
0.3-0.4um Super-Fine grain size solid carbide rod,Germany
Mutli-TIALN Coating (Black)--Arco,TiSiAlN(Copper),Platit
Made by 5 AXIS CNC grinder
Checked by Zoller Inspection Equipment
Workpiece upto HRC60
1 piece packing.
Standard Length Type
Description:
Super-Fine Grain Szie 0.3-0.4um, Wc carbide rod with high tenacity,with high quality TiAlN coating,getting
long tool life,from roughing to finishing processing,reduce time of changing cutters,improving efficency of
machine,saving time of making moulds.Suggest to process iron and steel upto HRC60,Middle-High speed.
Carbide Rod:Wc:90%,TRS:4000N/mm2, Grain Size:0.3-0.4um,HRA:93.5
Applications:
Fit for milling quenching and tempered steel.high wear resistance material,stainless steel.nickel alloy
andY Titanium alloy.Cast iron,enhanced composited material like Keviar and graphite,reinforced Plastics,
For PCB routers,for high speed cutting,for dry cutting.
Specifications:
|
Order No |
Cutting |
Flute Length |
Shank |
A.O.L |
|
d |
l |
D |
L |
|
|
1.0×3×4D×50L×4F |
1 |
3 |
4 |
50 |
|
1.5×4×4D×50L×4F |
1.5 |
4 |
4 |
50 |
|
2.0×6×4D×50L×4F |
2 |
6 |
4 |
50 |
|
2.5×8×4D×50L×4F |
2.5 |
8 |
4 |
50 |
|
3.0×8×4D×50L×4F |
3 |
8 |
4 |
50 |
|
3.5×10×4D×50L×4F |
3.5 |
10 |
4 |
50 |
|
4.0×11×4D×50L×4F |
4 |
11 |
4 |
50 |
|
3.0× 8×6D×50L×4F |
3 |
8 |
6 |
50 |
|
3.5×10×6D×50L×4F |
3.5 |
10 |
6 |
50 |
|
4.0×11×6D×50L×4F |
4 |
11 |
6 |
50 |
|
4.5×13×6D×50L×4F |
4.5 |
13 |
6 |
50 |
|
5.0×13×6D×50L×4F |
5 |
13 |
6 |
50 |
|
5.5×13×6D×50L×4F |
5.5 |
13 |
6 |
50 |
|
6.0×15×6D×50L×4F |
6 |
15 |
6 |
50 |
|
7.0×16×8D×60L×4F |
7 |
16 |
8 |
60 |
|
8.0 ×20×8D×60L×4F |
8 |
20 |
8 |
60 |
|
9 ×20×10D×75L×4F |
9 |
20 |
10 |
75 |
|
10×20×10D×75L×4F |
