Help CenterOutdoor P15mm Transparent LED Screen Rental For Stage , High Brightness
Related Products
-
P10mm Outdoor Rental Transparent LED Screen Curtain For Stage ShowUS$ $1 - $1MOQ: 1 Piece -
Lightweight Rental P15 Transparent LED Screen Curtain For StageUS$ $1 - $1MOQ: 1 Piece
-
Outdoor IP65 P12 Transparent LED Screen , Ultra Thin LED DisplayUS$ $1 - $1MOQ: 1 Carton
-
P10 Lightweight Outdoor Transparent LED Screen Curtain For EventsUS$ $1 - $1MOQ: 1 Piece
-
P12 Outdoor Transparent LED Screen , SMD 3535 Curtain LED DisplayUS$ $1 - $1MOQ: 1 Set
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. High brightness: >7000cd/㎡
2. Lightweight :< 8.5KG/panel. Ultra thin: 95mm thickness
3. Waterproof Level: IP65(Front Side), IP54 (Back Side)
4. CE,CCC,RoHS,UL,ISO9001
5. Made by excellent aluminum material
6. Cabinet connection angle can be adjusted by -15 degree to +15 degree
P15 Outdoor Transparent LED Screen Rental For Stage , High Brightness
Description:
1. High brightness & Waterproof
Brightness up to 7000nits, IP65 waterproof level. It provides a perfect solution for outdoor stage use.
2. Light Weight & Pretty Thin
Made by excellent aluminum material, each panel only weights 8.5 KG which makes installation job and
delivery be much more comfortable and convenient. Pretty thin, 95mm not only saves delivery
space but also saves installation space.
3. Angle Adjustment
Cabinet connection angle can be adjusted by -15 degree to +15 degree. This allows you shape arc
shapes.
4. Fast Lock System & Natural Cooling System Design
Fast lock system enables installation and dismantle to be much faster: an average worker can finish 50- 70
panels per hour. Natural cool system design results in good heat dissipation and less power consuming.
Applications:
Rental, Stage, Events, Show, Exhibition, Entertainment, Concerts
Specifications:
1. WS15 Technical Parameter
|
Model No. |
WS15 |
|
Pixel Pitch |
15.625mm |
|
Module Size |
500mm*62.5mm |
|
Module Resolution (W*H) |
32 dots*4 dots |
|
Pixel Density |
4096 dots/ ㎡ |
|
LED Type |
SMD 3535 |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/4 Duty Constant Current |
|
Cabinet Size |
500×500×95mm |
|
Cabinet Resolution |
32dots×32dots |
|
Brightness |
≥7000cd/㎡ |
|
Contrast |
≥4000:1 |
|
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
|
Best Viewing Distance |
7m-300m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
1500 W/m2 |
|
Average Power Consumption |
700 W/m2 |
|
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
60-85 HZ |
|
Refresh Frequency |
240 - 1000HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
-40~+65℃ |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
|
MTBF |
≥50,000 hours |
|
Comput |
