Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Lightweight :< 8.5KG/panel. Ultra thin: 95mm thickness
2. High brightness: >7000cd/㎡
3. Waterproof Level: IP65(Front Side), IP54 (Back Side)
4. CE,CCC,RoHS,UL,ISO9001
5. Made by excellent aluminum material
6. Cabinet connection angle can be adjusted by -15 degree to +15 degree
Lightweight Rental P15 Transparent LED Screen Curtain For Stage
Description:
1. Light Weight & Pretty Thin
Made by excellent aluminum material, each panel only weights 8.5 KG which makes installation job and
delivery be much more comfortable and convenient. Pretty thin, thickness 95m m not only saves delivery
space but also saves installation space.
2. High brightness & Waterproof
Brightness up to 7000nits, IP65 waterproof level. It provides a perfect solution for outdoor stage use.
3. Angle Adjustment
Cabinet connection angle can be adjusted by -15 degree to +15 degree. This allows you shape arc
shapes.
4. Fast Lock System & Natural Cooling System Design
Fast lock system enables installation and dismantle to be much faster: an average worker can finish 50- 70
panels per hour. Natural cool system design results in good heat dissipation and less power consuming.
Applications:
Rental, Stage, Events, Show, Exhibition, Entertainment, Concerts
Specifications:
1. WS15 Technical Parameter
|
Model No. |
WS15 |
|
Pixel Pitch |
15.625mm |
|
Module Size |
500mm*62.5mm |
|
Module Resolution (W*H) |
32 dots*4 dots |
|
Pixel Density |
4096 dots/ ㎡ |
|
LED Type |
SMD 3535 |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/4 Duty Constant Current |
|
Cabinet Size |
500×500×95mm |
|
Cabinet Resolution |
32dots×32dots |
|
Brightness |
≥7000cd/㎡ |
|
Contrast |
≥4000:1 |
|
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
|
Best Viewing Distance |
7m-300m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
1500 W/m2 |
|
Average Power Consumption |
700 W/m2 |
|
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
60-85 HZ |
|
Refresh Frequency |
240 - 1000HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
-40~+65℃ |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
|
MTBF |
≥50,000 hours |
|
Co |
