Portable GPS Tracking device Vehicle gps tracker 1000MAh Battery IPX6 Mini Waterproof car GPS Tracke

Delivery Time:WITHIN 3 DAYS AFTER PAYMENT
Certification:FCC ROHS

Portable GPS Tracking device Vehicle gps tracker 1000MAh Battery IPX6 Mini Waterproof car

GPS Tracker Can connect with car charger TKSTAR GPS Hidden gps tracker car 1000MAh Battery

IPX6 Mini Waterproof car GPS Tracker G-tkstar with system


This is a real time mini GPS tracker for kids / pets with a dimension of 50*50*20mm, such as cats dogs cows and sheep, with IPX6 Waterproof which can protect the unit from raining, cleaning and washing;1000MAh battery which can standby for 5-7 days and it can continuous work for 22-27 hours when at 5 minutes interval(transmit the data to platform),if the interval was longer then the GPS Tracker for pet(cat/dog)  would work longer, and sleep mode when does not moving.

Dimmension: 50mm x 50mm x 20mm

Battery:1000MAh

Feature:IPx6 waterproof  /long time standby / mini gps traccker / car gps tracker / can connect with car charger

Specifications:

LED INDICATOR STATUS	MEANING
Left-GREEN-Not lit	Device fault or dormant.
Left-GREEN-Continuously lit	No GPRS signal.
Left-GREEN-Flashing	GSM/GPRS communication established.
Center-RED-Not lit	Fully charged.
Center-RED-Solid red	Charging.
Center-RED-Flashing	Low battery.
Right-BLUE-Not lit	No power to the unit or the unit can’t start.
Right-BLUE-Continuously lit	Searching for GPS signal.
Right-BLUE-Flashing	GPS location successful.

Kind reminding: if you are in India, pls inform us ahead of time for the GSM module changing.

Quick Detail:

Name	Content
Dim.	50mm x 50mm x 20mm
Weight	50g
Network	GSM/GPRS Band 850/900/1800/1900Mhz
GPS chip	UBLOX
GPS sensitivity	-159dBm
Battery capacity	1000MAh
GPS accuracy	5m
Standby time	5-7 days
Worktime	22-27 hours (5mins interval)
Time To First Fix	Cold status  35-80s Warm status  35s  Hot status  1s
Car charger	12—24V  input       5V   output
Wall charger	110－220V  input        5V   output
Battery	Chargeable changeable 3.7V 1000mAh Li-ion battery
Temp.	-40°C to +85°C Operation Temp. -20°C to +55°C
Humidity	5%--95% non-condensing

Description:

This tracker is a personal remote location device with small size,build-in long standby time battery and easy to use.This tracker can be used as an emergency cellular phone and allows speed dialing 5 numbers for 2-way voice communication. It can sends alert and call the preset numbers for immediate assistance.The alerts include Date, Time, Coordinate, Speed and Map URL link. It will send the coordinate to the designated server by GPRS and then displaying the location by tracking software.

How to use the GPS tracker pet?
