Jack-Up Drilling Platform for Working Depth 50m

Jack-up Drilling Platform for Working Depth 50m.Introduction This platform is a steel non-propelled cantilevered three-leg self-elevating drillingplatform. Flat shape of the main hull is like triangle. Equipped with columnarlegs, an electric rack and pinion jacking system and a helideck. This platformis suit for working in argillo-arenaceous submarine offshore area or the similaroffshore area. Principal Parameters 1: Total Length x Total Width: 78mx50m;2: Hull: Length x Width x Depth: 58mx50mx5.7m;3: Leg: length x Diameter: 90mx?.5m;4: Cantilever (Length x Width x Depth): 30mx0.8mx4.5m;5: Derrick Movement Transversely: ?.5m; Longitudinally?2m;6: Drilling Capacity: 7000m(41/2in); 7000m(41/2 inDP); Electric Rig7: Lifting Capacity: 35tx32m; 2x35tx32m;8: Jacking Capacity: 2400MTx3;9: Working Depth: 5M~50m;10: Light Loading Draft: 11: Operating Environmental Temperature: -10oC~ +40oC;12: Fixed Number of Persons: 90;13: Self-sustaining Capacity: 20;14: Service Life-span: 20; producing area:China
