12000mm Length Seamless Titanium Tube Gr5 Gr3 With ASME SB338

12000mm Length Seamless Titanium Tube Gr5 Gr3 With ASME SB338 thumbnail-1
12000mm Length Seamless Titanium Tube Gr5 Gr3 With ASME SB338 photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
WSS
Place of Origin:
China
Model Number:
Contact Supplier Request Quote Chat Now
Wenzhou Seamless Stainless Steel Co., Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name WSS
Place of Origin China
Delivery Time:7-15days
Certification:ISO
  12000mm Length Seamless Titanium Tube Gr5 Gr3 With ASME SB338 Quick Details

seamless titanium tube
titanium oil fitting pipe
1.Size: OD(6-219)mm*WT(0.5-10)mm*L(MAX 12000)mm
2.Material: Gr1,Gr2,Gr3,Gr5,Gr9,Gr12
3.Standard: ASTM B337/338/861,ASME SB338

Seamless Titanium Tube information:

1)Grade: Gr1, Gr2, Gr3, Gr4 Gr5, Gr7, Gr9, Gr11, Gr12, Gr19, Gr23

2)Standard: ASTM B337  ASTM B338  ASTM B861

3). Allowable Deviation of Outer Diameter (mm)

Outer Diameter

Allowable Deviation

Outer Diameter

Allowable Deviation

3~10

±0.15

>50~80

±0.65

>10~30

±0.30

>80~100

±0.75

>30~50

±0.50

>100

±0.85

4). Allowable Deviation of Wall Thickness is not more than±10% of the Nominal WT

5). Allowable Deviation of Length(mm): L<12000

6). Curvature of Titanium Tube

Outer Diameter (mm)

Curvature (mm/m, not more than)

≤30

3

>30~110

4

7) OEM and customers’ designs are acceptable

  Nickel(Ni), Zirconium(Zr), Niobium(Nb) etc

8) Final product test:

Ultrasonic test, Eddy current test, Hydraulic test, Bend test, Flaring test and so on.

Product other description:

-Processing technique: seamless

-The diameter of tube is more than 219mm and the max length is  12000mm

-Seamless titanium tube can be used in many different areas

-Brilliant quality, perfect service, reasonable price offered

 ASME GR1/2 Mechanical Properties(Composion%)

Tensile Strength(Mpa)

Yield Strength0.2%(Mpa)

Elongation(%)

460

325

25



We are the manufacturer that special in producing titanium tube and other titanium products.

We provide you the certifications to guarantee the quality.

We are so glad to establish long term business relationship with trade firms and end user.

If you are interested in our products, please feel free to contact us, we will try our best to meet your demand

Applications:

(1)Heat exchangers and condensers

(2)Corrosive fluid transmission pipeline system

(3)Titanium bicycle tube, automobile exhaust pipe

(4)Offshore aquaculture

Specifications:

Item Name

Titanium Pipe

Grade

A1 TA2 TA3 TA9 TA18

Gr1 Gr2 Gr7 Gr9 Gr12 Gr16

3.7025 3.7035 3.7235 3.7195 3.7105

BT1-00 BT1-0

Standard

GB/T3624 GB/T3625 ASTM B337 B338 B861 B862

ASME SB338 ASME SB337 ASME SB861 SB862 DIN17861

Dimension (MM)

Φ10-Φ168 x0.5-10x 100-18000 MM

Application

heat exchanger coil pipe ;

Condenser; petroleum pipeline ; Sea farming

Evaporimeter;Fluid Transporation Piping etc.

Inspection Equipment

Nondestructive Tester; UT Testing Detector; Tensile Tester

Digital Ultrasonic Detector; Infrared Tester; HV Hardness Tester

Quality Guarantee:

(1) Main quality indicators:Chemical composition, mechanical property
