Industrial Extruder Temperature Control Unit AEX-10 with ISO Certificate

Delivery Time:20 – 35 work days
Certification:CE & ISO9001:2000

Industrial Extruder Temperature Control Unit AEX-10 with ISO Certificate

Quick Detail:

1. Explosion-proof equipment(optional)

2. Air blowing and return water function(optional)

3. Certification:CE & ISO

4. Automatic air-exhausting function after startup

5. Heating capacity: 4KW

6. Working pressure of pump: 2.2KW/cm2

7. Alarm function:open phase, water depletion, excess temperature, overloading, reverse turn

Description:

Explosion-proof equipment(optional) Thermometer for return water Function for forced cooling(optional) High-strength cooling capacity Automatic air-exhausting function after startup Switchover of heating power RS485 communication function for automated management(optional) Instant cooling shut-down function(optional) BY-PASS pressure release loop for hot water Carbon black resistant isolated electric box(optional) Customizable multi-point temperature control unit Customizable horsepower and heating power of water pump Direct cooling or indirect cooling(optional) Brands OMRON, FUJI, TE.LG, MOELLER, ABB and WEST for electric appliances Range of temperature control:+15℃-98℃ for incoming water Stainless steel integrated pipelines for less pipe resistance and rust Control mode: Imported microcomputer or PLC(optional) Perfect safety protection, fault display, easy repair and maintenance even without professionals

Specifications:

ITEM	UNIT	AEX-10
Temp control range	℃	Inlet water temperature +15℃-120℃
Temp control accuracy		PID±1℃
Power supply		AC3∮380V 50HZ 3P+E(5M)
Heat transfer medium		Water
Cooling method		Direct Cooling(indirect cooling can be customized)
Heating capacity	KW	4
Horsepower of pump	hp	1
Working flow of pump	L/min	100
Working pressure of pump	Kg/cm2	2.2
Max. power consumption	KW	5
Alarm function		Open phase/water depletion/Excess temperature/Overload/reverse turn
Cooling water pipe	inch	1/2
Circulating water pipe	inch	3/4
Size(L×W×H)	mm	525×260×530
Weight	kg	40

Competitive Advantage:

Our core competitiveness:advance technology,the pioneer of TCU industry, Convenient and efficient nationwide service network Excellent R&D team Customization thick copper pipe 1.0-1.2 Our core concept:Innovation, high-quality, integrity, service, focus High density heat insulation cotton and aluminum foil Electric appliances brands:OMRON, JUJI, TE.LG, MOLLER, ABB and WEST The thickness of our machine rack is 1.2mm We have the production certification organic heat transfer material heater

Applications:

Screw, Die head for extrusion industry
