Certification:CE & ISO9001:2000
Energy Saving 120 Degree Extrusion Temperature Controller Machine
Quick Detail:
1. Switchover of heating power
2. Instant cooling return oil shut-down function
3. Certification:CE & ISO
4. RS485 communication function for automated management(optional)
5. Heating capacity: 4×3KW
6. Working pressure of pump: 2.2KW/cm2
7. Customizable multi-point temperature control unit
Description:
Explosion-proof equipment(optional) Thermometer for return water Function for forced cooling(optional) High-strength cooling capacity Automatic air-exhausting function after startup Switchover of heating power RS485 communication function for automated management(optional) Instant cooling shut-down function(optional) BY-PASS pressure release loop for hot water Carbon black resistant isolated electric box(optional) Customizable multi-point temperature control unit Customizable horsepower and heating power of water pump Direct cooling or indirect cooling(optional) Brands OMRON, FUJI, TE.LG, MOELLER, ABB and WEST for electric appliances Range of temperature control:+15℃-98℃ for incoming water Stainless steel integrated pipelines for less pipe resistance and rust Control mode: Imported microcomputer or PLC(optional) Perfect safety protection, fault display, easy repair and maintenance even without professionalsSpecifications:
|
ITEM |
UNIT |
AEXT-10 |
|
Temp control range |
℃ |
Inlet water temperature +15℃-120℃ |
|
Temp control accuracy |
PID±1℃ |
|
|
Power supply |
AC3∮380V 50HZ 3P+E(5M) |
|
|
Heat transfer medium |
Water |
|
|
Cooling method |
Direct Cooling(indirect cooling can be customized) |
|
|
Heating capacity |
KW |
4×3 |
|
Horsepower of pump |
hp |
1×3 |
|
Working flow of pump |
L/min |
100 |
|
Working pressure of pump |
Kg/cm2 |
2.2 |
|
Max. power consumption |
KW |
21 |
|
Alarm function |
Open phase/water depletion/Excess temperature/Overload/reverse turn |
|
|
Cooling water pipe |
inch |
3/4 |
|
Circulating water pipe |
inch |
3/4×3 |
|
Size(L×W×H) |
mm |
800×600×1000 |
|
Weight |
kg |
110 |
Competitive Advantage:
Our core competitiveness:advance technology,the pioneer of TCU industry, Convenient and efficient nationwide service network Excellent R&D team Customization thick copper pipe 1.0-1.2 Our core concept:Innovation, high-quality, integrity, service, focus High density heat insulation cotton and aluminum foil Electric appliances brands:OMRON, JUJI, TE.LG, MOLLER, ABB and WEST The thickness of our machine rack is 1.2mm We have the production certification organic heat transfer material heaterApplications:
Screw, Die head for extrusion industry
Nowadays, Aode Machinery Co.,ltd continue to uphold the purpose of international standards designs and high quality products, applying ourselves to providing high stan
