Automatic 500ml PET Bottle Filling Machine , Liquor Beverage Filling Equipment

Delivery Time:20-40day after getting the bottle sample
Certification:CE,ISO9001:2001,BV

Automatic 500ml PET Bottle Filling Machine , Liquor Beverage Filling Equipment

Quick Detail:

Type: automatic filling machine for pulp juice Condition: New Application: pulp juice Packaging Type: Bottles, Automatic Grade: Automatic Driven Type: Electric Voltage: 220/380V Power: 2-10KW Place of Origin: Jiangsu, China (Mainland) Brand Name: Hyford Model Number: BRGF Series Weight: 3000-12000kg Certification: CE, ISO, SGS, BV After-sales Service Provided: Engineers available to service machinery overseas Material: High quality SUS304 stainless steel Filling Principle: Balanced Pressure Filling Number of Filling Heads: 12,18,24,32,40  Shipment: by Sea/Train

Description:

Automatic Filling Machine for pulp juice

The machine consists four parts: 1 rinser 2. pulp filler 3. juice filler 4. capper.

Filling accurately with pulp floating evently, and capacity from 2000B/H up to 15000B/H.

(1) Material: Stainless steel 304 /316

(2) Capacity: 3000-21000B/H(can be improved)

(3) Bottles type: PET, PVC, PP, Glass bottles.

(4) Bottle Hight: 150-340 mm

Electrical parts:

PLC programming controller      Mitsubishi/Siemens

Transducer                     Mitsubishi/Siemens

Touch screen monitor            Mitsubishi/Siemens

Main electrical components       SCHNEIDER

Pneumatic component           AIRTAC/FESTO

Specifications:

Automatic Filling Machine for Pulp Juice--Main data

Model	Washing Heads	Filling Heads for juice pulp	Filling Heads	Capping Heads	Production Capacity (b/h)	Main Power (KW)
BRGF18-8-18-6	18	8	18	6	4000	4.5
BRGF24-18-24-8	24	18	24	10	6000	5.5
BRGF32-24-32-10	32	24	32	10	10000	7.5

Competitive Advantage:

(1) Full filling is to avoid bottles from sinking after the bottles cooling off, and to decrease dissolved oxygen to the utmost extent.

(2) Reasonable structured storage hopper and material supply system keep material in the constant flow speed, constant pressure and without frothing. Usually high position tank is adopted.

(3) The storage hopper has the characteristics of gas discharge, full sealing and temperature detecting. In moderate and high speed production line, the material distributor replaces the big liquid tank to realize the complete CIP.

(4) Sanitary filling head system is of umbrella structure, high filling speed.

(5) Perfect filling temperature control system.

(6) Return tank system has the function of supplying the material automatically.

(7) Perfect CIP system

Hyford keeps 100% confident and try our best ability to satisfy customers\' requirements with their selected products. Additionally, Hyford owns a professional aftersale customer service team. Therefore, If you have any inquiries or questions, please visit our store, have a look other products and leave your message. Your message will be highly appreciated! Welcome to Hyford!
