1 - 12rpm Pallet Wrapping Machine for Carton box stack film wrapping, Soft drink, liquor

1 - 12rpm Pallet Wrapping Machine for Carton box stack film wrapping, Soft drink, liquor


To meet the packing requirement of containerization storage, transportation and mechanical loading and unloading, the automatic pallet stretch wrappers are widely used in export and industries such as beverage and food stuff, can making, paper making, dye, plastic and chemicals, glass, pottery and porcelain, and electromechanical castings to lower packing cost, increase product efficiency, prevent the goods from dusts and dampness and to protect the goods against damage during transportation.

Specifications:

Applications:

Features

Control System
- OMRON PLC Programmable Logic Controller
- Separate Carriage Up-Down Speed Control
- Auto-Height Load Height Sensing
- Electronic Film Tension Control
- Conveyor Jog (for each conveyor)
- Dust-tight Precious Metal Slip-ring for long reliable service
- Additional Controls may be required

Table Drive &Support
- 0-15 RPM Variable Table Speed (Higher Speeds Available Where Required)
- Adjustable Soft-Start Soft Stop
- Table Fully fenced for Greater Personnel Safety

Turntable Conveyor
- Heavy structural steel Frame construction
- Heavy duty Bearing Roller Support
- Soft-Start, Soft-Stop
- Different Roller Diameters and Roller Spacing Available for a variety of applications

Film Delivery System

- Powered pre-stretch system up to 200% to min film consumption
- Carriage door opens for effortless roll change and thread film
- Film delivery variable speed by separate DC Drive Motor
- Film dancer-bar with variable speed output
- Pre stretch Rate Set to Customers Requirements (200% Std)

Film Carriage Drive

- Two heavy duty ANSI #50 Chain Lifts (2)
- Programmable 3/4\" HP Variable Speed AC Drive Motor
- AC Motor Control Board
- UHMW-PE Glides on 3/8\" CRS Ways (No Maintenance Lifetime Warranty)

The safety fence is optional and not included in the offer.

Main Parts List:

PLC OMRON (JAPAN)
TRANSDUCER HLP (DENMARK)
AC CONNECTOR SCHNEIDER (FRANCE)
URGENT STOP SCHNEIDER (FRANCE)
PROCES SWITCH SCHNEIDER (FRANCE)
PHOTOELECTRIC SWITCH OMRON (JAPAN)
APPROACH SWITCH OMRON (JAPAN)
REDUCTION WITH GEAR BOX ZIBO (CHINA)
MOTOR WITH REDUCTION GEAR BOX TYT (TAIWAN, CHINA)
DC MOTOR (CHINA)
CONNECTION END PHOENIX (GERMANY)
