High Lumen Aluminum SMD2835 1200mm 18W T8 LED Tube 120 Degree , Warm White Office Lighting

Delivery Time:Sample order:3-5working days Mass order:7-15working days
Certification:CE ROHS

High Lumen Aluminum SMD2835 1200mm 18W T8 LED Tube 120 Degree , Warm White Office Lighting

Quick Detail:

self-produce 2835SMD T8,120cm,96pcs,18W Warm white/Natural white/Cold White 2 years warranty 85-277VAC 120Degree beam Angle

Description:

Input voltage:AC85V~277V Luminous Flux (lm):1728-2016lm Special heat sink design of LED tube can considerably reduce body temperature so that assure its lifespan over 50,000 hours. Tube Material:Aluminum+Clear/Milky/Clear PC cover Beam angle:120degrees LED Quantity:96pcs (SMD2835) Size:120cm/4ft(T8)

Specifications:

Power	18W
Input Voltage	AC85V~277V
Luminous Flux (lm)	1728-2016lm
Model Number	OS-OT84NW96
Size	120cm/4ft(T8)
LED Quantity	96pcs (SMD2835)
Tube Material	Aluminum+Clear/Milky/Clear PC cover
Beam angle	120degree
CCT	2700-6500K

Applications:

1. Supermarket

2. Production line

3. Fitting shop

4. Processing workshop

5. Store

6. Advertising lamp box

7. Office lighting, etc.

Competitive Advantage:

1. Using self-produce high power 2835 SMD with super bright and competitive price.

2. Energy conservation and environmental protection. LED tube could conserve more than 80% power compare with conventional lamp tube.

3 There will be no UV ray and infrared and contains no mercury in LED tube, with light emitting diode (LED) working as its lighting source.

4 Special heat sink design of LED tube can considerably reduce body temperature so that assure its lifespan over 50,000 hours.

5. Integrated design (heat sink is lamp shell) ensure request for heat conduction and elimination of LED and its life.

6. Large heat emission area will keep Tj<50°C (Ta=25°C) when LED working.

7. Creative optical design brings excellent illumination evenness.

Installation procedure:

1.Remover old tube and ballast

2.Remove starter and shortcut the ballast(for saving more energy)

be adequate for  inductive ballast

step1

step2

Step3

Step4

Working picture:

Package:

Certificates:
