18.5kw Metal Decking Sheets Roll Forming Machine Used on High Buildings

Delivery Time:45days
Certification:ISO,CE,SGS

18.5kw Metal Decking Sheets Roll Forming Machine Used on High Buildings

Introduction:

The metal deck forming machine is aided and optimized by computer. The metal deck produced by this machine has high strength with big wavelength. Used on high buildings , it not only saves steel mold plate, but also reduces the weight of storey. With the same bearing capacity, it economizes steel and cuts down investment accordingly.

·Professional designing for manufactures decking steel.

·Automatically continually manufactures high quality product with PLC.

·Easy operation : Directly Input the data on the touch screen.

·Customers decide the profile of products.

·Saving time and cost owing to high speed running with hydraulic system.

Technical Parameters:

Material Spec	Galvanized steel sheet
Thickness of Coil Sheet	0.8 --1.2 mm
Main Motor Power	18.5kw
Forming Speed	10--12m/min
Hydraulic Station Power	3kw
Quantity of Stands	About 24 groups
Hydraulic Pressure	10~12Mpa
Controlling System	PLC
Index Error of Length	10m±2mm
Total Weight	About 1800kg
Voltage	380V 3 phase 60Hz or at buyer’s requirement

Standard Equipment of Machine:

Passive uncoiler	1pc
Guiding equipment	1set
Rolling forming equipment	1set
Main body	1set
Post-cut equipment	1set
Hydraulic station	1pc
PLC controlling desk	1pc
Supporter table	2pcs
Security cover (optional)	1set

Advantage:

1. We use Automatic control software to manage productive information.

2. Thanks to the High integrated network, the whole automatic control system has an improvement in automaticity.

3. High performance in operation, maintenance, and debugging. Easy to load and unload.

4. First in quality

5. First in time

6. First in price

7. First in services

The profile drawing:

Working flow:

Photo of main roll forming machine:

Output table and manual decoiler:

Sample:

Factory scene:

Product certificates:
