Isolated EN 61347-1 Triac Dimmable Led Downlight Driver 700Ma 16W 24V

FOB Price

Negotiable / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	STARWELL		Place of Origin	China
Model Number	PE296B1670-1

Product Description

Delivery Time:10-15 days
Certification:UL,CE,ROHS, FCC,GS,SAA,C-TICK

Isolated EN 61347-1 Triac Dimmable Led Downlight Driver 700Ma 16W 24V

Short Features :

> Type : Dimmable Led Driver

> Dimming Manner : Trailing Edge & Leading Edge

> Model : PE296B1670-1

> input voltage range : 90-140VAC / 170-250Vac

> output : 12~24V 0~700mA 16W

> Output type : constant current

> Effiency : 90% Minimum

> PF : > 0.95

> Ripple and Noise : 100mV maximum

> Net Weight : 200g

> Dimensiont : 129(H)*44(W)*28(H)mm

> Certificate : SAA , C-tick , CE , ROHS certificates.

> Application : Led Street Light , Led Panel Light , Led Down Light , Led tube , etc ......

> Safety protection : over load, over voltage, short ciruict, open load protection.

Specifications

Input Rated Voltage :	90~140Vac / 170~250Vac
Input Frequency Range:	47Hz~63Hz
Input Inrush Current :	1.8A max
Efficiency :	85%(MIN)at Rated Voltage
Output :	12V~24V 0~700Ma
Output power :	16W
Ripple and Noise :	<150Mv at full road with 20MHz bandwidth
Turn On Delay Time:	<3S (AC:110V and full load)
Safety protection :	over voltage and current protection.
Leakage Current :	<5mA
Output type :	Constant current
Isolation rate :	isolation
Diming function :	Trailing edge & leading edge Triac dimming
Certificate :	CE GS TUV UL/CUL FCC ROHS,SAA,PSE,C-TICK
Safety Standard :	EN 55015:2006; EN 61547:1995+A1:2000 ;EN 61000-3-2:2006; EN61000-3-2:1995+A2:2005; EN 61347-1:2008 EN 61347-2-13:2006
Application :	For led light, led strip, led down light, led tube etc….

MODEL LIST:

Model	Power(W)	Input Voltage	Output Voltage	Output Current	LED Qty
PE296B0735-1	7W	170~250VAC (PE296BXX) 90~140VAC (PE296AXX)	12V~24V	0~350mA±1%	( improved model based on PE296 )
PE296B1230-1	12W	25V~42V	0~300mA±1%
PE296B1435-1	25V~42V	0~350mA±1%
PE296B1270-1	6V~15V	0~700mA±1%
PE296B1670-1	16W	12V~24V	0~700mA±1%
PE296B1830-1	18W	42~70V	0~300mA±1%
PE296B1843-1	25V~42V	0~430mA±1%
PE296B1850-1	18V~32V	0~500mA±1%
efficiency: 90%	PF>0.95	Dimension:	1294428mm	SAA, C-TICK, CE, TUV, ROHS
Dimming type:	Leading/trailing edge

Applications:

For led light , led strip , led down light , led tube etc ….

INSTRUCTION :

- For indoor application, can meet IP65 waterproof rate.
