300MA Constant Current Triac Dimmable Led Driver EN61547 + A1 70V

300MA Constant Current Triac Dimmable Led Driver EN61547 + A1 70V thumbnail-1
300MA Constant Current Triac Dimmable Led Driver EN61547 + A1 70V photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
STARWELL
Place of Origin:
China
Model Number:
PE299B2840
Contact Supplier Request Quote Chat Now
Shenzhen Starwell Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name STARWELL
Place of Origin China
Model Number PE299B2840
Delivery Time:10-15 days
Certification:UL,CE,ROHS, FCC,GS,SAA,C-TICK

300MA Constant Current Triac Dimmable Led Driver EN61547 + A1 70V

Short Features :

> Dimming Type : Trailing Edge & Leading Edge

> Model : PE299B2840

> input voltage range : 90-140VAC / 170-250Vac

> output : 43~70V 0~400mA 28W

> Output type : constant current

> Effiency : 90% Minimum

> PF : > 0.95

> Ripple and Noise : 100mV maximum

> Net Weight : 200g

> Dimensiont : 129(H)*44(W)*28(H)mm

> Certificate : SAA , C-tick , CE , ROHS certificates.

> Safety protection : over load, over voltage, short ciruict, open load protection.

> Application : Led panel , led down light , led street light , led tube , etc......

Specifications

Input Rated Voltage :

90~140Vac / 170~250Vac

Input Frequency Range:

47Hz~63Hz

Input Inrush Current :

1.8A max

Efficiency  :

85%(MIN)at Rated Voltage

Output :

 43~70V 0~400mA

Output power :

28W

Ripple and Noise :

<150Mv at full road with 20MHz bandwidth

Turn On Delay Time:

<3S  (AC:110V and full load)

Safety protection :

over voltage and current protection.

Leakage Current :

<5mA

Output type :

Constant current

Isolation rate :

isolation

Diming function :

Trailing edge & leading edge Triac dimming

Certificate :

CE GS TUV UL/CUL FCC ROHS,SAA,PSE,C-TICK

Safety Standard :

EN 55015:2006; EN 61547:1995+A1:2000 ;EN 61000-3-2:2006; EN61000-3-2:1995+A2:2005; EN 61347-1:2008 EN 61347-2-13:2006

Application :

For led light, led strip, led down light, led tube etc….

MODEL LIST :

Model Power(W) Input Voltage Output Voltage Output Current LED Qty
PE299B28120 28W 170~250VAC
90~140VAC		 12V~24V 0~1200mA±1%
PE299B2865 25~42V 0~650mA±1%
PE299B2840 43V~70V 0~400mA±1%
efficiency: 90% PF>0.95 Dimension: 183*50*32mm CE, ROHS
Dimming type: Leading/trailing edge

Applications:

For led light , led strip , led down light , led tube etc ….

INSTRUCTION :

- For indoor application, can meet IP65 waterproof rate.

- The mains plug is used as the disconnect device, the disconnect device shall be readily operable.

- The socket-outlet shall be installed near the equipment and shall be easily accessible.

- No naked flame source, such as lighted candles, should be placed on the apparatus.

- Maximum operating ambient for the equipment is 40℃.

- The apparatus should not be used in a confined space such as a bookcase.

- This appliance is not intended for use by persons (including children) with reduced physical,

sensory, or mental capacities, or lack of experience and knowledge, unless they have been given

supervision or instruction
