Black Wall Mount Australia 24W Router Power Adapter 12V 2A , Over Voltage Protection
Feartures:
> input voltage range: 100~240VAC
> Effiency: 85% minimum
> Ripple and Noise: 80mV maximum
> output: 12V 2A
> DC jack: 5.5*2.1*10mm
> Weight: 100g
> Color: Black or white
> Dc cable length: 1.5 meters/1.2 meters
> AC Plug: US , EU , AU ,UK plug avaliable
> Safety protection: over load, over voltage, short ciruict, open load protection.
Specifications:
|
Input Rated Voltage : |
100Vac~240Vac |
|
Input Frequency Range: |
47Hz~63Hz |
|
Input Inrush Current : |
0.3A max |
|
Efficiency : |
85%(MIN)at Rated Voltage |
|
Output: |
12V 2A |
|
Output power : |
24W |
|
Ripple and Noise : |
<80Mv at full road with 20MHz bandwidth |
|
Turn On Delay Time: |
<3S (AC:110V and full load) |
|
Safety protection : |
over voltage and current protection. |
|
Leakage Current: |
<5mA |
|
USB connector: |
5.5*2.1*10mm |
|
Operating Temperature: |
0°C----+60°C |
|
Storage Temperature: |
-20°C----+85°C |
|
Certificate: |
CE GS TUV UL/CUL FCC ROHS,SAA,PSE,C-TICK |
|
Safety Standard : |
EN60950-1 UL60950-1 ESD (EN61000 3-3) |
|
Application: |
For battery charger, mobile phone, cell phone, iphone etc… |
Model List:
24W SERIES
| Model | Input Voltage | Power | Output Voltage | Output Current | Plug type |
| SMS-01050400-S06EU | 100-240VAC | 20W | 5V | 4A | EU,US,UK,AU |
| SMS-01050400-S06US | |||||
| SMS-01050400-S06UK | |||||
| SMS-01050400-S06AU | |||||
| SMS-01070300-S06EU | 100-240VAC | 21W | 7V | 3A | EU,US,UK,AU |
| SMS-01070300-S06US | |||||
| SMS-01070300-S06UK | |||||
| SMS-01070300-S06AU | |||||
| SMS-01090300-S06EU | 100-240VAC | 27W | 9V | 3A | EU,US,UK,AU |
| SMS-01090300-S06US | |||||
| SMS-01090300-S06UK | |||||
| SMS-01090300-S06AU | |||||
| SMS-01120200-S06EU | 100-240VAC | 24W | 12V | 2A | EU,US,UK,AU |
| SMS-01120200-S06US | |||||
| SMS-01120200-S06UK | |||||
| SMS-01120200-S06AU | |||||
| SMS-01240100-S06EU | 100-240VAC | 18W | 24V | 1A | EU,US,UK,AU |
| SMS-01240100-S06US | |||||
| SMS-01240100-S06UK | |||||
| SMS-01240100-S06AU |
