RF Shielding 50 Ohm LMR Coaxial Cable With 2.74mm CCA Conductor , LMR 400 Low Loss Cable

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	KINGTONE OR OEM		Place of Origin	China
Model Number	LMR 400

Product Description

Delivery Time:Normally 15 days
Certification:ISO,CE,RoHS,UL

RF shielding 50 ohm LMR Coaxial Cable with 2.74mm CCA Conductor , LMR 400 Low Loss Cable

Quick Detail:

LMR 400 Low Loss Cable 2.74mm Copper Conductor High Quality 50 ohms Low loss Communication cable Designed for flexibility, low loss, RF shielding, and weatherability ISO,CE,RoHS,UL Short time delivery and stable quality inquire.

Description:

KT0505 LMR 400 Low Loss 50 ohms Coaxial Cable,2.74mm Copper,CCA Conductor

is a low loss, braided coaxial cable offers similar performance compared to corrugated

copper products but with higher flexibility and simplified connectorization.

Can be used in almost any application where handling characteristics, improved shielding

and low loss is required. LMR 400 is packed in 500FT/1000FT plastic/wooden spool,

and will be layed on pallet to protect the spool and easier carry.

Because of good managing methods, KINGTONE’S price of LMR 400

is not high although our quality is really high.

Applications:

Low loss at high frequency for radiocommunication and amateur radio.

KT0505 LMR 400 Low Loss 50 ohms Coaxial Cable, 2.74mm Copper/CCA Conductor
Construction Parameters:
Inner Conductor	2.74mm	Bare Copper/Copper Clad Aluminium
Dielectric	7.24mm	Foamed PE
First Shield	BONDED AL FOIL
Second Shield	Nom. 8.12mm	Tinned Copper Braid
Jacket	10.29mm	PVC (Color by your choise)/PE

Electrical Characteristics:
Capacitance	77.1 pF/m
Impedance	50 Ω
Velocity of Propagation	0.85
Shielding Effectiveness(>dB)	90
Min.Bend Radius(mm)	51
Operating Temp Range (PVC)	-25 ℃ to 70℃
Operating Temp Range (PE)	-40 ℃ to 80℃
RoHS	YES

Attenuation(20℃):
Frequency (MHZ)	Attenuation (dB/100m)	Avg.Power(KW)
30	2.2	2.91
50	2.9	2.21
150	5.0	1.28
220	6.1	1.05
450	8.9	0.72
900	12.8	0.50
1500	16.8	0.38
1800	18.6	0.34
2000	19.6	0.33
2500	22.2	0.29
5800	35.5	0.18

Order Informations:
Marking	KINGTONE LMR 400 COAXIAL CABLE XXX M
Inner Package	100M/200M/300M/500FT/1000FT
Outer Package	Carton, Color Box, Pallet (or Per customer\'s request)
Delivery time	Normally 15 days after received the deposit.
More informations	please contact with us.

Competitive Advantage:

1, From raw materials to final products, we perform intense quality checks to maintain our product quality:

A, Incoming material inspected by QC.

B, Manufacturing Process Control

C: Workers trained daily/weekly/monthly

D: Work instructions manual at each work station
