LMR 600 Low Loss 50 Ohms Coaxial Cable,4.47mm Copper,CCA Conductor

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	KINGTONE OR OEM		Place of Origin	China
Model Number	LMR 600

Product Description

Delivery Time:Normally 15 days
Certification:ISO,CE,RoHS,UL

KT0507 LMR 600 Low Loss 50 ohms Coaxial Cable,4.47mm Copper,CCA Conductor

Quick Detail:

LMR 600 Low Loss Cable 4.47mm Copper Conductor High Quality 50 ohms Low loss Communication cable Designed for flexibility, low loss, RF shielding, and weatherability ISO,CE,RoHS,UL Short time delivery and stable quality inquire.

Description:

KT0507 LMR 600 Low Loss 50 ohms Coaxial Cable,4.47mm Copper,CCA Conductor

is a low loss, braided coaxial cable offers similar performance compared to corrugated

copper products but with higher flexibility and simplified connectorization.

Can be used in almost any application where handling characteristics, improved shielding

and low loss is required. LMR 600 is packed in 500FT/1000FT plastic/wooden spool,

and will be layed on pallet to protect the spool and easier carry.

Because of good managing methods, KINGTONE’S price of LMR 600

is not high although our quality is really high.

Applications:

Low loss at high frequency for radiocommunication and amateur radio.

KT0507 LMR 600 Low Loss 50 ohms Coaxial Cable, 4.47mm Copper/CCA Conductor
Construction Parameters:
Inner Conductor	4.47mm	Bare Copper/Copper Clad Aluminium
Dielectric	11.56mm	Foamed PE
First Shield	BONDED AL FOIL
Second Shield	Nom. 12.50mm	Tinned Copper Braid
Jacket	14.99mm	PVC (Color by your choise)/PE

Electrical Characteristics:
Capacitance	76.8 pF/m
Impedance	50 Ω
Velocity of Propagation	0.86
Shielding Effectiveness(>dB)	90
Min.Bend Radius(mm)	75
Operating Temp Range (PVC)	-25 ℃ to 70℃
Operating Temp Range (PE)	-40 ℃ to 80℃
RoHS	YES

Attenuation(20℃):
Frequency (MHZ)	Attenuation (dB/100m)	Avg.Power(KW)
30	1.5	4.93
50	1.9	3.83
150	3.4	2.16
220	4.1	1.77
450	5.9	1.23
900	8.6	0.84
1500	11.4	0.63
1800	12.7	0.57
2000	13.4	0.54
2500	15.2	0.48
5800	25.0	0.29

Order Informations:
Marking	KINGTONE LMR 600 COAXIAL CABLE XXX M
Inner Package	100M/200M/300M/500FT/1000FT
Outer Package	Carton, Color Box, Pallet (or Per customer\'s request)
Delivery time	Normally 15 days after received the deposit.
More informations	please contact with us.

Competitive Advantage:

1, From raw materials to final products, we perform intense quality checks to maintain our product quality:

A, Incoming material inspected by QC.

B, Manufacturing Process Control

C: Workers trained daily/weekly/monthly

D: Work instructions manual at each work station
