Certification:CE,ROHS,CEC,ETL
AC To DC Lead Acid Battery Charger 12V1A , 12vdc Battery Charger , ETL CE CEC Approved
Feature:
. Input Voltage Range : 100 - 240Vac
. Class II Power
. Non - load consumption < 0.3W
. Protections: Over Current , Short Circuit , Over Voltage
. Approved By ETL/CE/CEC
. Warranties : 2 Years
Description:
12V1A AC To DC Battery Charger Approved By ETL CE CEC
|
Electronics Specification : |
|
|
Input Voltage Range : |
90 – 264Vac |
|
Input Frequency : |
50/60Hz |
|
AC Input Current : |
0.2A at Full Load and any Input Voltage |
|
Normal Output Voltage : |
12.0Vdc |
|
Maximum Output Current : |
950mA~1100mA |
|
Float Output Voltage: |
14.2 ~ 14.8Vdc (Red LED ON) |
|
Bulk Charge Mode Voltage: |
13.8 ~ 14.2Vdc (NO LED ON) |
|
Wet battery mode Voltage: |
13.4 ~ 14.8Vdc |
|
Maximum Output wattage: |
15.00W(At 1000mA load and any line) |
|
Line Regulation : |
±1% Maximum |
|
Load Regulation : |
±5% Maximum |
|
Efficiency : |
＞70% |
|
Output Short Circuit Protection : |
Can be Shorted without damage and auto recovery. |
|
Environment : |
|
|
Working Temp.: |
0~40℃ |
|
Working Humidity: |
20%~90% RH non-condensing |
|
Storage Temp. & Humidity: |
-20℃~85℃, 10%~95% RH |
|
Reliability : |
|
|
Hi-Pot Testing Voltage : |
I/P to O/P : 3.0 (60Sec.) KVac |
|
Safety Standard : |
EN60335-2-29 |
|
EMI Standard : |
EN55022B |
|
Mechanical Characteristics : |
|
|
Case : |
Euro (CEE) Version |
|
Case Size : |
(L) 75.7 * 47.5 (W) * (H) 31 mm |
|
Input Connector : |
2 Round Pins EU Version |
|
Output Cable : |
1.8M |
|
Output Connector : |
Red and Black clip, other type is available |
|
Safety Approval : |
|
|
Certificate: |
ETL, CE, CEC |
Led Instruction Manual
Charger Connect to 230Vac: LED Indication Red
Charger Connect to 230Vac and Connect to Battery when charging. The charging current over 0.25A: LED Off
Battery when Fully Charging and charging current below 0.25A: LED Indication Red
Certificate:
Applications:
widely used in household appliances, IT digital products, medical equipments, communication equipments, instrumentations, bank data equipment, computer peripheral products, security monitoring system, industrial and light field equipment and other products.
Factory Show:
