Certification:CE,ROHS,CEC,ETL
Interchangeable AC Plugs Lead Acid Battery Charger 100V - 240V AC Voltage Range
Feature:
. Input Voltage Range : 100 - 240Vac
. Interchangeable AC Plugs
. Non - load consumption < 0.3W
. Protection: Over Current , Short Circuit , Over Voltage
. Compliance To REACH / Rohs
. Warranties : 2 Years
Description:
12V2A Lead Acid Battery Charger Interchangeable AC Plugs
|
Electronics Specification : |
|
|
Input Voltage Range : |
90 – 264Vac |
|
Input Frequency : |
50/60Hz |
|
AC Input Current : |
0.3A at Full Load and any Input Voltage |
|
Normal Output Voltage : |
12.0Vdc |
|
Output Current : |
2.0A |
|
Float Output Voltage: |
13.80 ~ 14.2Vdc (Green LED ON) |
| Half Load Voltage : |
14.2 ~ 15.0Vdc (Orange LED ON) |
|
Bulk Charge Mode Voltage: |
14.2~ 15Vdc (Orange LED ON) |
|
Maximum Output wattage: |
30.00W(At 2.0A load and any line) |
|
Line Regulation : |
±1% Maximum |
|
Load Regulation : |
±5% Maximum |
|
Efficiency : |
＞70% |
|
Output Short Circuit Protection : |
Can be Shorted without damage and auto recovery. |
|
Environment : |
|
|
Working Temp.: |
0~40℃ |
|
Working Humidity: |
20%~90% RH non-condensing |
|
Storage Temp. & Humidity: |
-20℃~85℃, 10%~95% RH |
|
Reliability : |
|
|
Hi-Pot Testing Voltage : |
I/P to O/P : 3.0 (60Sec.) KVac |
|
Safety Standard : |
EN60335-2-29 |
|
EMI Standard : |
EN55022B |
|
Mechanical Characteristics : |
|
|
Case : |
Interchageable AC Plugs |
|
Case Size : |
(L) 94.5 * 50.5 (W) * (H) 33.5 mm |
|
Input Connector : |
Interchageable AC Plugs |
|
Output Cable : |
1.8M |
|
Output Connector : |
Red and Black clip, other type is available |
|
Safety Approval : |
|
|
Certificate: |
CE |
Led Instruction Manual
Charger Connect to 230Vac: LED Indication Red
Charger Connect to 230Vac and Connect to Battery when charging. The charging current over 0.25A: LED Off
Battery when Fully Charging and charging current below 0.25A: LED Indication Red
Applications:
widely used in household appliances, IT digital products, medical equipments, communication equipments, instrumentations, bank data equipment, computer peripheral products, security monitoring system, industrial and light field equipment and other products.
Factory Show:
