FIFO Selective Pallet Racking System 3tons/layer For Logistics Center
Quick Detail:
Good quality selective pallet racks & shelves ISO certificated
100% accessibility to individual pallets 98% utilization of pallet posting and 80% speed of access and throughput Stock rotation First in first out(FIFO) Easy picking lower levels Easily installed and repositioned Good storage density No special lift trucks requiredDescription:
Good quality selective pallet racks & shelves ISO certificated
Weitelong’s selective pallet racking is the most widely used storage system for fast moving palletized and non palletized loads which provides a broad range of flexibility for any heavy-duty storage needs.
The wide selection of components allow for an infinite variety of sizes to accommodate the most specific pallets, wire mesh box pallets, etc. Stocking vertically and horizontally maximizes available space without damaging inventory, while having the ability to access each individual load.
Selective Rack aisles and components can be sized to suit existing forklifts. Beams and frames are required in a variety of sizes according to load requirements of up to 3000KGS per layer.
Selective Pallet Racking installs quickly without tools and adjusts easily to your specific needs.
Advantages
Good stock rotation Good order picking, 100% selectivity allowing storage or retrieval of each pallet without moving others, as every pallet is individually accessible Can be designed to handle virtually any pallet size or weight Accessible by any type of forklift Most cost-effective and versatile of all storage solutions Provides fast handling of products Compatible with the majority of material handling equipment and warehouse environments The strength and integrity of the system provides maximum protection for the stock that is being storedSpecifications:
|
Classification: |
Heavy duty Pallet Racking |
|
Loading capacity: |
1000-3000 Kg per level |
|
Quality: |
Strong and stable |
|
Size: |
Customized size |
|
Materials: |
High quality steel Q235 |
|
Material thickness: |
1.5-2.5mm |
|
Upright: |
Omega Section |
|
Pitch holes: |
pitch 75mm square hole with good safety |
|
Beams: |
Box-shape beams or reinforced box-typed beam |
|
Levels: |
2~8 levels, customized |
|
Welding: |
Good neat welding |
|
Safety Pin: |
L shape locking pins |
|
Colors: |
Standard Blue & Orange or customized |
|
HS Code |
73089000 |
|
Maximum Height(Upright/Pillar): |
2000mm - 12,000 mm |
|
Max Width/Length(Beam): |
Up to 3,900 mm |
|
Max Depth(Upright frame): |
Up to 1,500 mm |
|
Max Weight: |
1,000kg - 3,000 kg / layer |
|
Mobility: |
The height of each beam can be adjusted by 75mm of pitch freely. |
|
Surface finish: |
Powder coating which is characterized by surface-smoothly, antirust, anti-corrosive, non-toxic. |
|
Color: |
Blue/Orange/Gray/others |
Applications:
warehouse & logistics, food/drug distribution, petroleum/chemical plants, a
