Automatic Commutator Fusing Machine ( Weling Machine) For DC Motor And Universal Motor

Ningbo Nide Mechanical Equipment Co.
Automatic Commutator Fusing Machine ( Weling Machine) For DC Motor And Universal Motor thumbnail-1
Automatic Commutator Fusing Machine ( Weling Machine) For DC Motor And Universal Motor photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Nide
Place of Origin:
China
Model Number:
ND-LWD-104CSPSJ-S2
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Nide
Place of Origin China
Model Number ND-LWD-104CSPSJ-S2
Delivery Time:35 working days
Certification:None

Automatic Commutator Fusing Machine ( Weling Machine) For DC motor And Universal Motor

Quick Detail:

1. Commutator OD ranges from15~40mm.
2. Armature OD. φ10mm-φ50mm
3. It has colorful touch screen, and data setting can be done on the touch sreeen.
4.This machine is equipped with conveyor so that it can be connected with other machine to make a armature production line.
5. This machine is controlled by PLC.
6. It can weld both riser and hook type commutators.

Application:

 It can weld both riser and hook type commutators. This machine is applied to DC motor and universal motor.

Description:

This machine can automatically fuse, and operator only need to load and unload rotor. It can weld both riser and hook type commutators. This machine is applied to DC motor and universal motor. It is controlled by PCL, all the data setting can be done on the touch sreeen. There are four power control method, namely secondary constant current, secondary constant voltage secondary constant frequency.


Specification:

1.   Feeding method: automatic feeding. Loading and unloading
2.   Parameter setting: touch screen and power parameter setting
3.   Power control method: current feedback, high precision counter current
4.   Commutator type: both hook type and raise type
5.   Wire diameter  0.1mm-1.2mm
6    Armature OD. φ10mm-φ50mm
7.   Shaft OD: φ5mm-φ15mm
8.   Commutator O.D.: φ15mm-φ40mm
9.   Commutator slot/hook number: ≤36
10.   current range: 0.5-50KA
11.   Voltage range: 0.1-9.99V
12.   Power range: 1.00-99.99KW
13.   Power control method: secondary constant current, secondary constant voltage secondary constant frequency
14.   Welding standard parameter range(1-63groups)
15.   Electric parameter testing setting range:  current: 00.00-99.99KA(0.01KA per unit), voltage: 00.00- 99.99V(0.01V per unit), Frequency: 00.00-99.99KW(0.01KW per unit)
16.   Cooling method: water cooling
17.   Air  source : 4kg/cm2—6kg/cm2
18.   Power supply:  three phase AC380V±10%  50HZ  40KW
19.   Machine weight: 800kg
Competitive advantages:

This machine is easy for operation. Equipped with conveyor, this machine can be connected with other machine to make a armature production line. It’s helpful for customer to reduce labor cost and improve production efficiency.
