Automatic Hook And Riser Type Commutator Fusing Machine With Conveyor
Negotiable
1 (Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Flexiblity Commutator Fusing Machine With Walking Beam System , PLC Control
-
Automatic Commutator Fusing Machine ( Weling Machine) For DC Motor And Universal Motor
-
High Performance Automatic Commutator Welding Machine For Fusing Commutator Bar
-
PCL Controlled Automatic Commutator Fusing Machine for DC And AC Motor
-
Servo Single Tool Commutator Turning Machine With Aluminum Alloy Frame
-
Mechanical , Electrical Auto Armature Turning Machine For Washing Machine Motor Rotor
Product Details
| Brand Name | Nide | Place of Origin | China | |
| Model Number | ND-LWD-104CSPSJ-S2 |
Product Description
Certification:None
Automatic Hook And Riser Type Commutator Fusing Machine With Conveyor
Quick Detail:
1. Model No.: ND-LWD-104CSPSJ-S2
2. Commutator OD ranges from15~40mm
3. This machine is controlled by PLC.
4. It has colorful touch screen, and data setting can be done on the touch sreeen.
5. It can weld both riser and hook type commutators.
6. This machine is equipped with conveyor so that it can be connected with other machine to make a armature production line.
Description:
This machine is applied to DC motor and universal motor. It is controlled by PCL, all the data setting can be done on the touch sreeen. It can weld both riser and hook type commutators.There are four power control method, namely secondary constant current, secondary constant voltage secondary constant frequency. This machine can automatically fuse, and operator only need to load and unload rotor.
Application:
This machine is applied to DC motor and universal motor. It can weld both riser and hook type commutators.
Specification:
1. Feeding method: automatic feeding. Loading and unloading
2. Parameter setting: touch screen and power parameter setting
3. Power control method: current feedback, high precision countercurrent
4. Commutator type: both hook type and raise type
5. Wire diameter 0.1mm-1.2mm
6 Armature OD. φ10mm-φ50mm
7. Shaft OD: φ5mm-φ15mm
8. Commutator O.D.: φ15mm-φ40mm
9. Commutator slot/hook number: ≤36
10. current range: 0.5-50KA
11. Voltage range: 0.1-9.99V
12. Power range: 1.00-99.99KW
13. Power control method: secondary constant current, secondary constant voltage secondary constant frequency
14. Welding standard parameter range(1-63groups)
15. Electric parameter testing setting range: current: 00.00-99.99KA(0.01KA per unit), voltage: 00.00- 99.99V(0.01V per unit), Frequency: 00.00-99.99KW(0.01KW per unit)
16. Cooling method: water cooling
17. Air source : 4kg/cm2—6kg/cm2
18. Power supply: three phase AC380V±10% 50HZ 40KW
19. Machine weight: 800kg
Competitive advantages:
This machine is easy for operation. Equipped with conveyor, this machine can be connected with other machine to make a armature production line. It’s helpful for customer to reduce labor cost and improve production efficiency.
