16 Port 15.4W 802.3af PoE Switch With 2 Gigabit SFP Combo Port

16 Port PoE switch with 2 Gigabit SFP Combo port

Quick Detail:

◆ IEEE 802.3af power on up to 16 ports
◆ Supports PoE power up to 15.4W for each PoE port
◆ Supports PoE power up to 250W for all PoE ports


To fulfill the demand of sufficient PoE power for network applications with 10/100Mbps wire speed transmission, ONV introduces a new member in the IEEE802.3af PoE Fast Ethernet Switch family – POE31016P, the 16-Port 10/100Mbps IEEE802.3af Power over Ethernet Switch with 270 Watts PoE budget. The 16 Fast Ethernet ports integrated with IEEE802.3af PoE injector function are able to drive at least 16 x IEEE 802.3af 15.4 Watts Class 3 compliant powered devices.
The POE31016P also provides a simple, cost-effective, and non-blocking wire-speed performance with 19-inch metal shape for deployment in compact housing, SOHO office or department network application.



Product features

◆ IEEE 802.3af power on up to 16 ports
◆ Supply power to wireless access points and surveillance cameras over Cat-5 cabling
◆ 16 10/100 Mbps Ports with AutoUplink™
◆ Supports PoE power up to 15.4W for each PoE port
◆ Supports PoE power up to 250W for all PoE ports
◆ Supports PoE IEEE 802.3af compliant PDs
◆ Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
◆ 8K entry MAC address table of the PoE Switch POE31016P with auto-learning and auto-aging
◆ LED indicators for monitoring power, link, activity and speed
◆ External power adapter supply



Target Industries

◆HD monitor transmission and power supply
◆Wireless AP layout transmission and power supply
◆Network telephone transmission , intelligent house and home
system
◆Intelligent transportation supervisory system(ITS)
◆ High-speed Way supervisory/Tele-Communication System
◆ Security protection system, TV medical treatment
◆ Long-distance Muti-media Schooling, Campus monitoring
◆ Long-distance broadcast television transmission system
◆ High-building Security Protection, Military Tele-Com projects
