API 5L GRA/GRB ERW STEEL PIPE
1.Technical Data
Standard | ANSI,ASTM ,API.DIN,GB.JIS |
Material | A106 Gr A,B,A53 Gr B,ASTM A179,A106GrB,ASTM A53GrB,St42,St45,A179,A135,A315B,A214CA333 Gr 6,A335 P11,A335 P22,TP304,TP321,TP316,TP304L,TP316L,A335 P5,ST37,ST35.8,ST52,1.0309, |
OD | 1/4"-40",13mm-1000mm |
WT | SCH5,SCH10,SCH20,SCH40,SCH60,SCH80,SCH100,SCH120,SCH160,XXS |
Usage | Structure Use,water transport,Building,Machinery,Traffic,Aviation,Oil development ect. |
OD Tollerance | D<50mm,+-0.5mm ,D>50MM,+-1% |
WT Tollerance | WT +-12.5% |
Chemical | C:0.17-0.24%,Si:0.17-0.37%,MN:0.35-0.65%,P:<0.035%,S:<0.035%,Cu:<0.25%,Ni<0.25%,Cr:<0.25% |
Tensile strength | 390MPA |
Yield Point | WT<16MM 245MPA,WT 16-30MM 235MPA |
Elong-Ation | 20 |
other test | HY,ET according to request |
Length | 2-12m Random,5.8M FIXED,6M FIXED,9M FIXED |
Suface | Black paint as rusty protect |
Ends | 2"below plain ends,2" above beveled ends |
Methord | 140mm below cold drawn,140mm above hot rolled,273mm above hot expand |
Packing | 6 steel strip,bundles,Caps , plastic wrap,loading belt |
erw pipe |
Reference standard |
ASTM, JIS, EN,API |
material |
10#,20# ,45# |
grade |
X42--X70 ,Q235 |
