Flame Proof Electrical Generator Paralleling Switchgear For Mining
Description:
KBZ-630/1140(660)Z mine use flame-proof intelligent vacuum feed switches are suitable for underground mines containing explosive gas (methane) and coal dust. They are is used as general switches for power distribution, or branch switches in a 50Hz, 1140V or 660V and current up to 400A (630A) 3-phase electrical network with non-directly earthed neutral. They have protection functions for short circuit, overload, phase failure, leakage, leakage-lockup, under voltage and overvoltage. FLEX I/O control module may be provided as an option for realizing remote monitoring. They employ a 16 bit MPU for intelligent control, using Chinese(English) character LCD to display fault signals of the running parameters. They detect current and output of fault protections. It provides some basic protections and start/stop control, such as, belt misalignment, lockup, coal piling up, belt slip, etc., as well as function of loud-speaking telephone. They adopt rapid door-open structures. They provide a built-in control module, FLEX I/O, as an option for remote control.
Competitive Advantage:
16-bit MPU intelligent control, Chinese (English) character LCD to indicate fault signals of the running parameters, detection of current and output of fault protection, rapid door-open structure and the built-in optional module FLEX I/O for remote control.
Specifications:
|
Item |
Content |
|
KBZ-630/1140(660)Z |
|
|
Rated voltage |
1140/660V |
|
Rated operational system |
Continuous |
|
Rated current |
630A |
|
Overall dimensions/weight |
970*690*950/ 500kg |
|
Max breaking capacity |
1140V 12.5kA |
|
Outside diameter of incoming cable |
Power line: 32 -78mm |
|
Type of protection |
Mine use flame-proof type Exd I |
|
Protection function |
abnormal voltage, overload, short-circuit, phase failure, leakage-lockup, leakage protection, overvoltage and under voltage |
|
Fault protection output |
2circuits: short-circuit/leakage, overload/phase failure |
|
Current frequency output |
Current signal: DC1-5mA |
|
Display |
Running parameters: voltage, current, insulation resistance and electric network frequency |
|
Setting |
Rated current, rated voltage, rapid-breaking current, rapid-break delay, leakage delay |
|
Data communication |
RS485 or Device Net interface |
Certifications
manufacturing license / MA mine security certification / flame proof certification.
Production Facility:
