6 tons Q345B Steel Construction Tower Crane , TC6013-6 QTZ100

6 tons Q345B Steel Construction Tower Crane , TC6013-6 QTZ100

TC6013-6 tower crane (QTZ100)

1. Specification: TC6013-6

2. Dimensions: standard section 1,600mmX1,600mmX3,000mm

3. Material: All main chord is in Q345B steel

4. Application: Suitable for construction of medium and high-rise commercial, civil buildings and such large projects as roads and bridges, power stations, etc. as well as construction of large goods yard, wharf, etc.

5. Parameter: Maximum hoisting capacity 6 tons, the longest jib is 60 m, maximum independent lifting height 48m, maximum attached height 181m

6. Model number:QTZ100

Quick Detail:

1. The tower crane is an outside climbing and self-elevating tower crane with horizontal jib, trolley travelling and upper rotray.

2. The longest jib is 60m, the jib length combination reduces for every 5m and the minimum arm length is 45m.

3. The maximum hoisting capacity is 6 tons.

4. The maximum lifting capacity at a distance of 60m is 1.3 ton.

5. The maximum hoisting moment is 131t.m.

6. The maximum free height is 48m and the maximum ancorages height is 181m.

7. Hoisting mechanism: Adopting a three speed winding motor   24KW for power. Slew mechanism: Adopting a double gyration winding motor  3.7 KWX2 for powe. Hoisting mechanism: Adopting a double-speed winding motor   3.3KW for power

8. The mast used monolithic standard section of 1,800mmX1,800mmX2,800mm or 1835mmX1835mmX2500mm,or chip standard section of 1,600mmX1,600mmX3,000mm.

9. Tower crane foundation type: Embeded leg fixing type. Stone bolt fixing type

Description:

Our main products are: Hammer head tower crane QTZ63(TC5013),QTZ80(TC5610,TC5610A,TC6010,TC6010A)QTZ100(TC6013-6,TC6013A-6,TC6013-8,TC6013A-8)QTZ125(TC6015-8,TC6015A-8,TC6512-10,TC6512A-10)QTZ160(TC7013-10,TC7013-12)QTZ250(TC7520-12,TC7520-16)

Flat head tower crane QTZ125(TCP6015-8,TCP6512-10)QTZ160(TCP7013-10,TCP7013-12)

TC6013-6(QTZ100)Tower Crane is a high-end self-elevating tower crane designed according to the needs of construction for small and medium-sized cities. The performance parameters and technical indicators are leading domestically. The outline of the whole unit is of a type in fashion internationally and very beautiful, being deeply liked by domestic and foreign users; The rated hoisting moment is 100t·m, maximum are length is 131t.m, maximum hoisting weight is 6t independent height 48m,attached height181m,highest hoisting height for special cargo can reach to 200m.

Applications:

TC6013-6(QTZ100)tower crane attached type can reach the highest height 181m, which are suitable for use in project construction in such industries as water conservancy and hydropower, metallurgy, petroleum, chemical, thermal power, etc., suitable for use in modern industry and civil building construction and lifting of electromechanical equipment for industrial enterprises and suitable for use in project construction of railways, roads, bridges, ports, airports, etc.

Specifications:

Table for main technical performance parameters for TC6013-6 tower crane:
