8 Ton 180m QTZ125P Flat Top Tower Crane For Construction / Wharf

8 Tons 180m QTZ125P Flat Top Tower Crane For Construction / Wharf

TCP6015-8 tower crane (QTZ125P)

1. Flat top tower crane with convenient installation and disassembly, it is very suitable for crossing tower crane groups.

2. Standard section of 1,800mmX1,800mmX2,800mm or 1835mmX1835mmX2500mm,or plate standard section of 2,000mmX2,000mmX3,000mm.

3. The longest jib is 60m,  the  jib combination  decreases progressively 5 meters each and the minimum jib length is 40m.

4. The maximum hoisting capacity is 8 tons.

5. The maximum lifting capacity at a distance of 60m is 1.5 ton.

6. The maximum hoisting moment is 135t.m.

7. The maximum independent height is 59m and the maximum attached height is 180m.

8. Hoisting mechanism: Adopting a variable frequency motor   30KW . Slew mechanism: Adopting a torque motor   3.7 KWX2. Luffing mechanism: Adopting a variable frequency motor    3.3KW.

9. Tower crane foundation type: Embeded leg fixing type. Stone bolt fixing type

Description:

Our main products are:

Hammer head tower crane QTZ63(TC5013), QTZ80(TC5610, TC5610A,TC 6010, TC6010A), QTZ100(TC6013-6, TC6013A-6, TC6013-8, TC6013A-8), QTZ125(TC6015-8,TC6512-10,), QTZ160(TC7013-10, TC7013-12), QTZ250(TC7520-12, TC7520-16)

Flat head tower crane QTZ125(TCP6015-8, TCP6512-10), QTZ160(TCP7013-10, TCP7013-12)

TCP6015-8(QTZ125P) Adopting the plate type standard section which can be exchanged with POTAIN\'s one.

Specifications:

Table for main technical performance parameters for TCP6015-8 tower crane:
