Commercial Advertising LED SMD Display Indoor Full Color 32 x 16dots 1/8 scan

Items

P6

Classification of items

Full color

Application environment

indoor

Pixel pitch

6mm

LED lamps

Silan SMD3528

Optimum viewing distance

5m

Optimum viewing angle

H:140°V:140°

Module size

192X96mm

Module resolution

32x16dots

Physical pixel

27777 dots/m2

Pixel constitution

1R1G1B

Cabinet size

768X768mm

Cabinet resolution

128X128dots

Cabinet material

Iron coated epoxy

Cabinet structure

Indoor fixed

Typical power consumption

800W/sqm

 Driving method

1/8 scan Constant Current

Frame frequency

≥60Hz/s

Refresh Rate

≥400Hz/s

Luminance of White Balance

≥1200 Nits

Operating environment temperature

 -10°C - +50°C

Working voltage

110-220VAC+-10%

Grey Scale/ Color

Displaying colors≥16.7M(Synchronized)

Brightness Adjustment

256 levels of each color

Input singal

RF,S-Video,RGB,RGBHV,YUV,YC & Composition,etc

Software

LED studio(LINSN)

Control system

PCTV card(optional)+ DVI display card+ main controller card (sending card and receiving card)+ optic fiber transmission(optional)

Average level of no failure time

>5000 hours

Life span

>100,000 hours

Malfunction Dot Rate

<0.0001
