12V 120W Power Supply AC To DC Switch For 3528 / 5050 LED Strip Waterproof IP67

Delivery Time:5-10 days
Certification:CE,ROHS

12V 120W Power Supply AC To DC Switch For 3528 / 5050 LED Strip Waterproof IP67

Quick Detail:


12V 120W Power Supply AC to DC Switch for 3528 5050 LED Strip Waterproof IP67 Brand: VOTOO waterproof design for outdoor use Package:white paper box protections:Short circuit/Overload/Over Temp OEM/ODM welcome Warranty: 1 year

Description:


Features:

o Output Voltage: 12V

o Output Current: 10A

o Power: 120Watt

o Ripple & Noise: 1% of Output Voltage

o Leakage Current: 0.25mA

o No load power Consumption

o Working Temperature:0-40°C Max

o Efficiency:78%Min

o Universal Input 100~240VAC 50/60Hz

o Small volume, light weight, high efficiency.

o Cooling by free air convection.

o 100% Full load burn-in test.

o One year warranty.

Weight: 1100g

o Dimensions: 180*70*40mm

o Accurate information and descriptions.

o All orders are shipped on time.

o All items are fully inspected prior to shipping to meet international standards by our QC staffs.

o All items are with CE RoHS approval to ensure the products quality.



Specification:


Model	12V 120W Power Supply AC to DC Switch for 3528 5050 LED Strip Waterproof IP67
DC Current	10A
DC Voltage	12VDC
Rated Power	120W
Input Voltage	110~240VAC
Over Voltage Protection	130%
Over Power Protection	130%
Efficiency	88%
Life Span	50000hrs
MTBF	250Khrs
Withstand Voltage	I/P-O/P: 3KVAC, IP-FG:1.5KVAC, DC-FG: 500VAC
Working Temperature	-35~+70°C
Size	180*70*40mm

How to Install?

• Make sure work in proper environments are stated in this Guide.

• Do not overload.

• Avoid free of load while a power supply is powered on, keep proper loading

• Always keep good ventilation

• Do not mount on wood or flammable surface, keep minimum 5CM for LED power supplies each other.

• Keep away from inflammable or explosive environments.



Applications:

1. CCTV security, door access, digital camera, etc.

2. POS machine, mini printing machine, etc.

3. Electronic scale, flowerpot etc.

4. LED strip, LED lighting etc.
