Three Pin 110-240V AC To 24V 3A Switching Power Adapter For Advertisement Display

Delivery Time:5-10 days
Certification:CE,ROHS

Three Pin 110-240V AC To 24V 3A Switching Power Adapter For Advertisement Display

Quick Detail:

Type: desktop type  24V 3A Switching Power Adapter No load power consumption< 0.3W 100% aging test before shipment 100% spot check before shipment Certificate: CE & RoHS OEM/ODM welcome 1 year warranty

Features:

1)Input :AC 110-240V 50/60HZ

2)Output:DC 24V 3A

3)Power:72W

4)Output promg:LCD prong

5)Connector size:5.5*2.5mm

6)Package includes:1 cord 1 adapter

7)Warranty:1 year

o One year warranty.

o Output Voltage: 24V

o Output Current: 3A

o Power: 72Watt

o Ripple & Noise: 1% of Output Voltage

o Leakage Current: 0.25mA

o No load power Consumption

o Working Temperature:0-40°C Max

o Efficiency:86%Min

Protections

1) over voltage protection: 120%min
2) over current protection: 120%min
3) over protection

4) Short-circuit protection: automatic recovery ­

5) Load regulation: ±5%

Environmental requirement

1)operating temperature: 0-40

2)storage temperature: -20-85

3)opera ting relative humidity:595%RH

4) Withstanding voltage: AC 3,000V (minimum), 5mA (maximum)

­

5) Insulation resistance: DC 500V 100MΩ (minimum) ­

Weight: 380g

Dimensions: 140*60.5*34.5mm

1. AC input power suitable for the world2. Soft-start current can reduce the AC input impact efficiency

3. With short-circuit and overload protection

4. Compact size ,light weight

5. 100%full-load burning test

6. Installed with EMI filter ,minimum wave

Specification:


InPut Charactoritics

Output power(max): 1-120W

Input voltage : 100-240Vac

Input frequancey: 50-60hz

Output Charactoritics

Output Voltage: 24V

Output Amp:3A

Output Watt: 72W

Condition: Brand New

OEM equivalent part, 100% compatible as genuine part!

How to Install?

Before connecting check whether the power supply fullfields electrical specification (output voltage and current). Also check the socket type and its polarity. Connect power supply to the supplied unit. Power supply must be connected to a working electrical AC line with a voltage of 100-240V. Do not install power supply in locations with high humidity, dust or strong direct sunlight. The power supply should be installed in a location with good airflow. Power supply can only be installed indoors. AC wire should connect tight with adapter socket, in case poor contact socket.



Applications:

1. CCTV security, door access, digital camera, etc.

2. POS machine, mini printing machine, etc.

3. Electronic scale, flowerpot etc.

4. LED strip, LED lighting etc.
