Certification:ISO9001, CE
Capacity(T/H): 0.8~3 Feeding size(mm): ≤Φ800 Output size(mm): ≤50×50 Motor power(Kw): 45+4 Main shaft speed(RPM): 16 Weight(T): 7.6
Quick Detail:
The tire shredder (crusher) adopts low noise, steady and high torque planet gear speed reducer, easy and safe operation.
Description:
ZPS Tire Shredder is used to shred radial tire and fiber tire into tire chips of 50x50mm size in ambient process, the tire needs to be debeaded before shredding. It mainly consists of motor, speed reducer, machine frame, shredding blades, rotary screener, transmission system, etc.
Structure and Principle
The shredding chamber adopts folio compact structure for easy maintenance;
The shredding blade edges are made of hard alloy after special hardness treatment, wear-proof. The blade edges are made replaceable without dismantling the machine, blades changing and repairing jobs are made easy and not costly any more. Heavy-duty, advanced technology and high output;
The machine adopts low noise, steady and high torque planet-gear speed reducer, easy and safe operation;
The rotary screener is of steel net structure which has large area for screening qualified size of tire chips to discharge quickly. Low consumption, high output and advanced technology.
Applications:
To Shred tyres into 5*5cm block
Specifications:
|
Model |
800 |
800E |
|
Capacity(T/H) |
0.8~3 |
0.8-3 |
|
Feeding size(mm) |
≤Φ800 |
≤800 |
|
Output size(mm) |
≤50×50 |
≤50×50 |
|
Motor power(Kw) |
45+4 |
45+4 |
|
Main shaft speed(RPM) |
16 |
16 |
|
Weight(T) |
7.6 |
7.6 |
Competitive Advantage:
1. Easy Operation
2. Big capacity
3. We have a design of exchangeable blades which is very easy for repair and replacement.
Tag: Tire shredder, crusher, tire recycling
