Help Center0-2.5GHz SMA Head WLAN Gas Tube Antenna Surge Arrestor
Related Products
-
0-2.5GHz N Head Gas Tube Antenna Wlan Surge ArresterNegotiableMOQ: 1 Piece -
0.4-0.5 GHz N Head Quarter Wavelength Antenna WLAN Surge ArresterNegotiableMOQ: 1 Piece
-
0.8-2.2GHz D Head Quarter Wavelength WLAN Antenna Surge ProtectorNegotiableMOQ: 1 Piece
-
0-3.0GHz N Head Gas Tube Antenna WLAN Surge ProtectorNegotiableMOQ: 1 Piece
-
0-6.0GHz N Head Gas Tube Antenna WLAN Ligthning ArresterNegotiableMOQ: 1 Piece
Application
1) Various transmit-receive system of radio-frequency signal
2) Network signal wireless transmit-receive equipment
3) Industrial control signal wireless transmit-receive equipment
4) Satellite television (SATV) receiving equipment
5) Surveillance signal wireless transmit-receive equipment
6) Other wireless communication equipment
7) Other radio-frequency signal equipment
Feature
1) Big working bandwidth
2) Feed power supply
3) High discharge current capacity, low residual voltage
4) Low insertion loss and Standing-wave ratio (SWR)
5) Quick response
6) Precise limiting voltage
7) Stable performance, reliable working
8) Compact size
Specification
Model |
AR25S |
Working frequency |
0-2.5 GHz |
Max continuous working voltage |
≤70V |
Nominal discharge current |
5KA |
Max discharge current |
10KA |
Insertion loss |
≤0.2 dB |
Standing-wave rate (SWR) |
≤1.2 |
Interface type |
SMA-K/J |
Working conditions |
Temperature:－40～＋85℃; Relative humidity:≤95％(25℃); Elevation≤3km |
Note: For latest information, please contact ANSUN company |
Installation and wiring
a) To reliably protect lightning, to connect a antenna SPD in each side of antenna output and protected device terminal. In low lightning strike frequency area or in the condition of antenna without amplifier, only to install a antenna SPD in protected device terminal.
b) The earth lead, as short as possible (section area above 4mm2), is welded on the lug of antenna SPD, and the other side of SPD closely connects to the earth bus of lightning protection system
c) To apply rain-proof type product outdoors, but if no rain-proof function, please make necessary precaution
